2.2.2

Cable Connections

TABLE 2-3
TABLE 2-3
System
SPARC Enterprise
M4000 Server
Connector
SPARC Enterprise
M5000 Server
Connector
Note – For servers that have the B-type plug, confirm that a 20A overcurrent
protection device is available outside the server. If one is not available, prepare an
external 20A overcurrent protection that can be achieved by means of no-fuse
breakers (NFBs) or fuses. The B-type plug refers to plugs other than grounding-type
ones with two parallel blades, such as the NEMA L6-30, L6-20, L6-15, and L5-15.
Refer to the SPARC Enterprise M4000/M5000 Servers Site Planning Guide for electronic
specifications of the midrange servers.
2.2.3

Checking the Installation Location

When installing the server, consider not only the device sizes but also the sizes of the
required service areas (maintenance areas). For details, refer to the SPARC Enterprise
M4000/M5000 Servers Site Planning Guide and the manual that came with the rack.
The site electrician should verify the proper electrical hookups.
2-8 SPARC Enterprise M4000/M5000 Servers Installation Guide • February 2012
lists the power cords for the servers.
Power Cords
Location
Americas, Taiwan
Korea, Japan
Rest of the world
Americas, Taiwan
Korea, Japan
Rest of the world
Power Cord Type
NEMA L5-15 125V 15A
NEMA L6-20 250V 20A
IEC60309 16A 250V, 3PIN with IEC 60320
C20
NEMA L5-15 125V 15A
NEMA L6-20 250V 20A
IEC60309 16A 250V, 3PIN with IEC 60320
C20
