Chapter 5 Replace Brick Spare Disk Drives
The figure below shows a spare disk drive.
Figure 52 Spare disk drive FRU
The figure below identifies the location of the spare disk
drive, which is accessed from the back side of the Brick.
Figure 53 Spare disk drive location
Locking
tabs
Screws
Pillar Data Systems Confidential
Back
Brick back
Front
Spare disk
drive module
