Mounting Your Webster TS Whiteboard on a Wall

You will need a tape measure, Phillips screwdriver, and drill.
To mount the Webster TS whiteboard on a wall:
1 Choose a location with convenient access to your computer, an
AC power outlet, and any network connections or projectors you
are using.
2 Carefully mark two drill hole locations as indicated below, based
on your Webster TS whiteboard model:
(2335 mm)
Model
TS 400
TS 600
TS 800
3 Using the mounting plates as a template, mark two additional
drill hole locations that are 3/4
4 For sheet rock walls, screw the self-tapping sheet rock anchors
into the wall using a power driver, if available. Wall anchors for
6
TS 800
92"
77" (1950 mm)
Distance from the Distance between
floor to the holes
74"
(1880 mm)
77"
(1950 mm)
77"
(1950 mm)
TS 600 TS 400
62"
(1575 mm)
(1070 mm)
77" (1950 mm)
hole locations
42"
(1070 mm)
62"
(1575 mm)
92"
(2335 mm)
(19 mm) from the original hole.
"
42"
74" (1880 mm)
