2. INSTALLATION AND CONFIGURATION
2.1 TYPICAL SYSTEM CONFIGURATION
Additional Speed Dome joystick controllers and a variety of external switching devices
such as multiplexers (MUXes) and Digital Video Recorders (DVRs) may be incorporated
to accommodate the needs from a small to a large surveillance/security system.
Figure 1 illustrates sample installation.
Figure 1 - Typical System Configuration
9
Mini PTZ Speed Dome
