4. Press and hold down the SHFT/PGM key while controlling the camera direction
and zoom with the Joystick. The pattern movement will automatically be
recorded until releasing the SHFT/PGM key. This procedure can be repeated to
reprogram the pattern.
(Or twist zoom handle or hit zoom button to start PTZ control for view selection and
hit the Focus button to stop.)
5. Scroll down to the Save and Exit option and move the Joystick to the right to
save and exit.
6. Naming the Pattern can be done by twisting the Joystick. Rotate the handle
clockwise or counterclockwise to scroll through the alphanumeric characters,
move the handle to right or left to select next or previous space.
7. Pressing ESC will not save recorded data and will exit to the previous menu.
Press the HOME or OFF button at any programmed position to delete the
programmed pattern.
NOTE: If total recording time reaches 120 seconds, it will automatically stop for a
moment and start recording again. Previous data will be overwritten.
3.1.4 SCAN ( MENU => FUNCTIONS => SCAN or Shortcut: SCAN )
The Scan function supports up to 4 programmed sections of angles at 8 programmable
speeds.
SPEED (MODE):
SCAN MENU
SCAN 01
SPEED
START
END
DIRECTION : CCW
SWAP
SAVE AND EXIT
1/ 2 / 3/ 4/ 5/ 6/ 7/ 8/ SLOW / MEDIUM
1: SLOWER ↔ 8 FASTER
SLW : smooth DiagonalScan in slowest speed
MID : smooth DiagonalScan in medium speed
DiagonalScan shows moving path from start point to end point
including tilt and zoom** simultaneously.
**Some models do not change zoom ratio
01/8
: AUTOSCAN01
: 1~8/SLW/MID
: NONE
: NONE
: OFF
26
Mini PTZ Speed Dome
