Page 2
NUVICO. • NUVICO makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or malfunction of the cameras, peripheral devices, or unapproved/un...
Warning and Caution WARNING! TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OPENINGS ON THE EQUIPMENT. CAUTION! The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
FCC Compliance Statement FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST H ARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED I N A COMMERCIAL ENVIRONMENT.
Important Safeguards • Read these instructions. • Heed all warnings. • Follow all instructions. • Do not use this equipment near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Table of Contents ...................... Disclaimer ..................Warning and Caution ..............FCC & CE Compliance Statement ..................Important Safeguards ................... Table of Contents 1. Introduction ..................About this Manual ....................Key Features ..................Content Verification ..................Camera Dimensions 2. Installation and Configuration ..............
Page 7
. Programming the Screen Functions ....................3.3.0 Screen ................... 3.3.1 Language ..................3.3.2 Privacy Zone ................... 3.3.3 North Direction .................... 3.3.4 Zone Title ..................3.3.5 Camera Title ..................3.3.6 OSD Display . Programming the Camera Functions ....................3.4.0 Camera ..................3.4.1 Focus Control ..................
1. Introduction ABOUT THIS MANUAL Thank you for purchasing our EasyTrak™ PTZ speed dome camera. Our EasyTrak™ PTZ dome cameras are all equipped with high resolution 1/4” CCD Imager for enhanced lowlight sensitivity. A user-friendly, on-screen display (OSD) menu make it easy to setup and program functions. System information aides troubleshoot- ing by displaying the hardware and software version of the camera’s firmware, baud rate,and protocol.
1. Introduction Content Verification Before installing the camera, please make sure that all of the following items are included in the box. EasyTrak™ PTZ Dome Series 1. EasyTrak™ PTZ Dome Camera 2. Aluminum Pendant Housing w/ Wall Mount (Pendant Housing Model) 3.
2. Installation and Configuration 2.1.1 Typical System Configuration Additional Controller Keyboard and a variety of external switching devices such as Multiplexers (MUXes) and Digital Video Recorders (DVRs) may be incorporated to accommodate the needs from a small to a large surveillance/security system. Figure.1 Illustrates Sample Installation Configuration...
2. Installation and Configuration 2.1.2 Basic Configuration of EasyTrak™ PTZ Dome System Figure.2 Illustrates the Basic Installation Configuration POWER AC 24V STP AWG # 22 J-BOX BACK J-BOX FRONT SLAVE 1 DOME 2 RS-232C DC12V ALARM/PC + - + - + - ALARM / DVR BNC MONITOR REAR...
2. Installation and Configuration 2.1.3 Connecting the EasyTrak™ PTZ Dome Directly to the DVR • Locate the RS-422 Rx+ & Rx- conductor wire from the EasyTrak™ PTZ dome. • Connect the RS-485 Tx(+)/ Tx(-) of the DVR into Rx(+)/Rx(-) of the PTZ dome camera.
2. Installation and Configuration 2.1.5 Connecting the EasyTrak™ PTZ Dome to the DVR via J-box Figure.5 Illustrates connecting EasyTrak™ PTZ dome & DVR into the Controller Keyboard DOME 1 DOME 2 DATA 1 SLAVE 1 DOME 2 RS-232C + - + - + - ALARM / DVR DATA 1 REAR...
2. Installation and Configuration 2.1.6 DIP Switch Layout Diagram EasyTrak™ PTZ dome camera must be installed by a qualified service personnel only. Before installing this camera system, Instruction Manual must be read thoroughly and fully understood. This setup procedure involves proper setting of the configu- ration switches indicated below.
2. Installation and Configuration 2.1.7 Principle of Termination Every device that is connected at the end of the communication data line must be terminated by either the DIP switch setting or an appropriate device such as a termination jumper to prevent potential control signal errors. See Figure.6 for termination switch settings and Figure.7 for examples of devices requiring termination.
Page 16
2. Installation and Configuration 2.1.7 Principle of Termination (Continued) Figure.7 Illustrates the PTZ dome camera termination diagram DVR Termination ON S1:Dome1 port Termination ON SW1:Termination ON SW1:Termination ON S1:Dome1 port Termination ON DVR Termination ON SW1:Termination ON SW1:Termination ON SW1:Termination ON SW1:Termination ON DVR Termination ON DVR Termination ON...
2. Installation and Configuration 2.1.8 EasyTrak™ PTZ Dome Camera Address (ID) Each EasyTrak™ PTZ dome camera must have a unique address (ID). Identical IDs on the same line may damage the control circuit caused by an electrical short. When installing multiple cameras or a DVR, it is recommended that cameras ID’s be indentical to the camera port of the DVR.
2. Installation and Configuration 2.1.9 Setting Protocols EasyTrak™ PTZ dome camera is capable of supporting multiple protocols if the com- munication speed is matched (same baud rate i.e., 9600 bps). All EasyTrak™ PTZ dome camera comes with ‘Auto Detection’ as factory default for optimal performance. Note: Consult service personnel if the PTZ dome camera is installed with a device other than a recommended PTZ camera controller.
2. Installation and Configuration 2.2.0 Connections • How to Connect to RS-485 The EasyTrak™ PTZ dome camera has built-in RS-485 receiver so that it can be controlled remotely by an external control device such as a Controller Keyboard or a DVR. RS-485: Connect the TXA (Tx+) and TXB (Tx-) of the RS-485 control devices (KBD, DVR...) to TRX+, TRX- of the dome camera.
Page 20
2. Installation and Configuration 2.2.0 Connections (Continued) • NO / NC (Normally Opened or Normally Closed dry contact relay output) EasyTrak™ PTZ dome camera can activate external devices such as buzzers or lights using dry contact relays. Connect the device to the NO (NC) (Alarm Out) and COM (Common) connectors.
2. Installation and Configuration 2.2.1 Mounting the EasyTrack™ PTZ Dome Camera Make sure that all the DIP switches are properly configured, and the external connections all properly connected before mounting the PTZ camera to any surface. The EasyTrak™ PTZ camera is designed to mount on a structural body supporting load of up to 5 Kg. Figure.11 Example of Typical Ceiling Mounted Installation YELLOW STICKER YELLOW STICKER...
2. Installation and Configuration 2.2.2 Power On & Boot-Up Sequence When power is applied to the EasyTrak™ PTZ camera, it will automatically start its boot-up sequence. The following information is displayed once the boot-up sequence is complete. RAM TEST CHECK NO. : OK! CHECK AAAA : OK! CHECK 5555 : OK! SD SERIES...
3. Program & Operation 3.0 Dome Camera Selection Prior to programming or operating the EasyTrak™ PTZ dome camera, please make sure that both the camera and the Controller Keyboard is communicating. In order for changes to take effect, particular dome camera’s ID must be selected on the controller. Example: Pressing [1] then [6] then [CAM] key sequentially will select the camera 16.
3.1 Programming the PTZ Functions IMPORTANT: This section covers the programming of EasyTrak™ PTZ dome camera when directly connected to the NUVICO Controller Keyboard. For programming using only the DVR, please refer to your DVR manual. 3.1.0 Function Access the the ‘FUNCTION’ section of the OSD Main menu to designate a Home Function, program Presets, Patterns, Scans, or setup complicated Tours.
3.1 Programming the PTZ Functions 3.1.1 Home Function ([MENU] Button _ Function _Home Function) IMPORTANT: Before this function can be utilized, please program the Presets,Tour, Pat- terns, or AutoScan prior to designating the ‘HOME FUNCTION.’ The ‘Home Function’ recalls the predefined function, such as Preset, Tour, Pattern, or AutoScan as the default function after an assigned period of inactivity passes.
Page 26
3.1 Programming the PTZ Functions 3.1.2 Preset ([MENU] Button _ Function _ Preset [Preset]) Preset is designed to store Pan, Tilt, Zoom, focus and Iris settings. Once programmed, pressing the combination of [0~9] number buttons followed by the [Preset] button on the Controller Keyboard ([0~248] _ [Preset]) will automatically recall the predefined preset.
Page 27
3.1 Programming the PTZ Functions 3.1.2 Preset (Continued) 4. You may enable or disable the FOCUS, IRIS, BLC, or WDR fields by twisting the Joystick handle while the cursor is over their respective fields. (A=Automatic, M=Manual, F=OFF, O=On) 5. Move the cursor over to the ‘TITLE’ field, enter the custom name for the Preset. Using the Joystick, navigate the 16-digit title space twisting the Joystick handle to scroll through the alphanumeric characters.
Page 28
3.1 Programming the PTZ Functions 3.1.3 Pattern ([MENU] Button _ Function _ Pattern [Pattern]) The Pattern function is designed to store and memorize complicated movements of the EasyTrak™ PTZ dome camera for up to 240 seconds. Once programmed, pressing the combination of [0~4] number buttons followed by the [Pattern] button on the Controller Keyboard ([0~4] _ [Pattern]) will automatically recall the predefined pattern.
Page 29
3.1 Programming the PTZ Functions 3.1.3 Pattern (Continued) 3. Move the cursor over to the ‘TITLE’ field, enter the custom name for the Pattern. Using the Joystick, navigate the 16-digit title space twisting the Joystick handle to scroll through the alphanumeric characters. 4.
Page 30
3.1 Programming the PTZ Functions 3.1.4 Scan ([MENU] Button _ Function _ Scan [Scan]) The Scan function is designed to store and memorize 2 specific points of the surveillanced perimeter--the START point and the END point. Once programmed, the EasyTrak™ PTZ dome camera will start the scan from the designated start point and move horizontally or diagonally to the end point and back in the predetermined speed.
Page 31
3.1 Programming the PTZ Functions 3.1.4 Scan (Continued) 4. Move the cursor down to the ‘START’ option. While pressing down the [Shift] button, use the Joystick and aim the camera to the desired start location. Release the [Shift] button to designate the start position.
Page 32
3.1 Programming the PTZ Functions 3.1.5 Tour ([MENU] Button _ Function _ Tour [Tour]) There are 8 programmable Tours. Each Tour can consist of up to 8 Presets, Patterns, Scans or other Tours. Using this method, a single Tour can be expanded up to 56 functions. However, if a Tour is programmed with another Tour, but a second-level Tour is already embedded with another, the third-level Tour will be skipped while running the first-level Tour.
Page 33
3.1 Programming the PTZ Functions 3.1.5 Tour (Continued) TOUR 01:xxxxxxxxxxxxxxxx 01/08 FUNC NO S DW TITLE PRST 064 S 03 ---------------- PTRN 004 S 03 ---------------- xxxxx: 16 Digit Tour Title SCAN 016 S 03 ---------------- ------: Undefined Functions/Speed/Dwell/Titles TOUR 004 S 03 ---------------- S (Speed): F - Fast (Normal) / M - Medium / S - Slow ---- --- - 03 ---------------- DW (Dwell): 01-99 Sec.
Page 34
3.1 Programming the PTZ Functions 3.1.5 Tour (Continued) 4. By default, the ‘NO’ slot will automatically be set to ‘01.’ Move the cursor over to ‘NO’ and define the function number by scrolling through the available programmed functions. 5. The speed and the dwell time is automatically fill-out to the default setting of Slow and 3 seconds.
3.2 Programming the Alarm 3.2.0 Alarm ([MENU] Button _ Alarm) The Alarm function is designed to trigger specific pre-programmed functions of the Easy- Trak™ PTZ dome camera when there is changes in the input status. The PTZ dome camera reports the alarm state to the Controller Keyboard. MAIN MENU FUNCTION ALARM...
3.2 Programming the Alarm 3.2.0 Alarm (Continued) ALARM SETUP NO FUNC PRI OUT HLD LATCH 01 P01 OFF OFF 001 02 048 OFF OFF 001 03 001 OFF OFF 001 04 --- OFF OFF 001 05 --- OFF OFF 001 06 --- OFF OFF 001 07 ---...
Page 37
3.3 Programming the Screen Functions 3.3 Screen ([MENU] Button _ Screen) Access the the ‘SCREEN’ section of the OSD Main menu to setup a Privacy Zone, designate a North Direction, enter a custom Camera Title, or enable or disable other various OSD settings.
Page 38
3.3 Programming the Screen Functions 3.3.1 Language ([MENU] Button _ Screen _ Language) The default language for the EasyTrak™ PTZ dome camera is English. The default can not be changed. 3.3.2 Privacy Zone ([MENU] Button _ Screen _ Privacy Zone) This function is used to conceal specific areas within the frame of the camera.
Page 39
3.3 Programming the Screen Functions 3.3.2 Privacy Zone (Continued) 2. Move the cursor to Zone 01, while pressing down the [Shift] button, aim the camera to an area you wish to mask. Once the camera is pointed to the desired location, release the [Shift] button to designate the masking area.
Page 40
3.3 Programming the Screen Functions 3.3.3 North Direction ([MENU] Button _ Screen _ North Direction) North Direction is a user-defined setting that may correspond to magnetic north or well- known landmark. It is used to approximate the camera’s pointing direction while Direction Indicator is in operation.
Page 41
3.3 Programming the Screen Functions 3.3.4 Zone Title (Continued) ZONE TITLE 01/04 TITLE START 01 WINDOW 123.4 345.6 ----- ---- ----- ---- ----- ---- ----- ---- ----- ---- PREV NEXT SAVE AND EXIT 2. To enter the Zone Title, while highlighting ‘01,’ twist the Joystick handle. Once the desired custom name has been entered, press down on the Joystick handle.
Page 42
3.3 Programming the Screen Functions 3.3.5 Camera Title ([MENU] Button _ Screen _ Camera Title) A custom title for the EasyTrak™ PTZ dome camera can be entered to easily identify between the many other cameras that may be connected to the DVR or network. >>...
Page 43
3.4 Programming the Camera Functions 3.4.0 Camera ([MENU] Button _ Camera) Access the the ‘CAMERA’ section of the OSD Main menu to setup the Focus Control, adjust the WB Control, setup the AE Control, enable or disable the Backlight, adjust the Sharpness, setup the Digital Zoom, configure the Night Shot, and reset the Camera to the Factory Default.
Page 44
3.4 Programming the Camera Functions 3.4.1 Focus Control ([MENU] Button _ Camera _ Focus Control) The Focus Control function is used to tune the sensitivity of the Auto Focus, or turn off the automatic function entirely to conserve the lifespan of the lens in highly active (movement heavy) areas.
Page 45
3.4 Programming the Camera Functions 3.4.3 AE Control ([MENU] Button _ Camera _ AE Control) The AE Control (Automatic Exposure) function is used to manually control the Iris, Slow Shutters, Gain, Brightness, and WDR (Wide Dynamic Range). It can also be set to ‘FULL AUTO’...
Page 46
3.4 Programming the Camera Functions 3.4.4 Night Shot ([MENU] Button _ Camera _ Night Shot) EasyTrak™ PTZ dome camera automatically converts to B/W mode in the absence of adequate lighting to reduce digital noise and add higher contrast. The Night Shot function allows the user to force the Color mode under poor lighting, or B/W mode during daytime.
Page 47
3.5 Programming the Setup Functions 3.4.5 Camera Default ([MENU] Button _ Camera _ Camera Default) The Camera Default function is used to reset only the ‘CAMERA’ programming to the factory default setting. This function will NOT erase the ‘FUNCTION’ programming, such as Presets, Patterns, Scans, or Tours.
Page 48
3.5 Programming the Setup Functions 3.5.0 Setup ([MENU] Button _ Setup) Access the the ‘SETUP’ section of the OSD Main menu to setup the Flip Function, adjust the PTZ speed, setup the Panning Range limit, setup the Tilt Over Angle, Calibrate the PTZ dome camera, setup a Line Lock, reset the PTZ dome camera to the factory default, Erase the ‘FUNCTION’...
Page 49
3.5 Programming the Setup Functions 3.5.1 Flip ([MENU] Button _ Setup _ Flip) The EasyTrak™ PTZ dome camera is designed to automatically digitally ‘FLIP’ the image while tracking a target moving directly below the PTZ dome camera. SETUP MENU FLIP FUNCTION : ON SPEED : FAST PANNING RANGE...
Page 50
3.5 Programming the Setup Functions 3.5.3 Panning Range (Continued) PAN RANGE SETUP RIGHT LIMIT : 000.0 LEFT LIMIT : 007.2 (007.2) ENABLE : ON / OFF SWAP RIGHT/LEFT SAVE AND EXIT >> To program the ‘Panning Range,’ please follow the instructions below. 1.
Page 51
3.5 Programming the Setup Functions 3.5.4 Tilt Over Angle ([MENU] Button _ Setup _ Tilt Over Angle) This function is used to set the limit of the horizontal view angle (Tilt), so that the trim ring or the ceiling does not obstruct the horizontal image when zooming-out (Wide Angle). VIEW ANGLE SETUP TILT OVER ANGLE : ON SAVE AND EXIT...
Page 52
3.5 Programming the Setup Functions 3.5.5 Calibration ([MENU] Button _ Setup _ Calibration) The EasyTrak™ PTZ dome camera is equipped with Auto-calibration which is capable of maintaining accurate operation through constant self-correction. Once this function is enabled, EasyTrak™ PTZ dome will go through a series of Pan/Tilt movement and align its vertical and horizontal position against several check points.
Page 53
3.5 Programming the Setup Functions 3.5.6 LIne Lock ([MENU] Button _ Setup _ Line Lock) This function is used to prevent the vertical video rolling when switching between multiple cameras to a single monitor. If the PTZ dome camera is experiencing video roll- ing, Line Locking the camera will synchronize the picture on the screen.
Page 54
3.5 Programming the Setup Functions 3.5.7 Factory Default ([MENU] Button _ Setup _ Factory Default) The Factory Default function is used to reset the EasyTrak™ PTZ dome camera to the factory default setting. This function will erase all data and programming. ‘FUNC- TION’...
Page 55
3.5 Programming the Setup Functions 3.5.8 Erase Data ([MENU] Button _ Setup _ Erase Data) The Erase Data function is used to reset only the ‘FUNCTION’ programming to the factory default. The ‘CAMERA’ programming such as, Focus Control, WB Control, or AE Control will not be affacted.
Page 56
3.5 Programming the Setup Functions 3.5.9 System Information ([MENU] Button _ Setup _ System Information) System Information can be viewed by accessing this option. The information may be needed for servicing and troubleshooting purposes. 1. Press the [Menu] button on the Controller Keyboard. Select the ‘SETUP’ option. Scroll down to ‘SYSTEM INFORMATION,’...
Troubleshooting Tips If problems occur, verify the installation of the camera with the instructions in this manual. Isolate the problem from the equipments in the system and refer to the equipment manual for further information. Problem Solution Verify that power is connected to all components in the system.
Page 58
Technical Specifications | NTSC Technical Specifications SD-Z36N Video Format NTSC Image Sensor 1/4” CCD Horizontal Resolution 530 TV Lines Wide Dynamic Range Day/Night Functionality Yes w/ ICR Lens Type 36X A/F Optical Zoom 3.4-122.4mm (Auto Focus & Auto Iris) 12X Digital Zoom (Total: 432X) Angle of View 57.8°(W) ~ 1.7°(T) Communication...
Page 59
Technical Specifications | PAL Technical Specifications SD-Z36P Video Format Image Sensor 1/4” CCD Horizontal Resolution 530 TV Lines Wide Dynamic Range Day/Night Functionality Yes w/ ICR Lens Type 36X A/F Optical Zoom 3.4-122.4mm (Auto Focus & Auto Iris) 12X Digital Zoom (Total: 432X) Angle of View 57.8°(W) ~ 1.7°(T) Communication...
