Indoor & Vandalproof Dome Cameras
NUVICO INC.
Tel: 201-541-1605 Fax: 201-541-1620
Toll Free: 866-523-1700
E-mail: techsupport@nuvico.com
www.nuvico.com
NUVICO EasyView and the NUVICO logo are registered trademarks of NUVICO.
© Copyright 2006, NUVICO. All rights reserved.
TM
Indoor & Vandalproof Dome Cameras
SD Series w/ 36 LEDs
Flush Mount Housing
INSTALLATION
TM
Flush Housing w/
Surface Mount Plate
Wall Mount
MANUAL
Advertisement
Table of Contents
Related Manuals for Nuvico EasyView CD-H266
Summary of Contents for Nuvico EasyView CD-H266
- Page 1 Tel: 201-541-1605 Fax: 201-541-1620 Surface Mount Plate Toll Free: 866-523-1700 E-mail: techsupport@nuvico.com www.nuvico.com NUVICO EasyView and the NUVICO logo are registered trademarks of NUVICO. © Copyright 2006, NUVICO. All rights reserved. SD Series w/ 36 LEDs Flush Mount Housing Wall Mount...
-
Page 2: Table Of Contents
Table of Contents About This Manual Before installing and using the camera, please read this manual carefully. Be sure to About This Manual keep it handy for later use. This installation manual covers the following models listed below. Any difference in features for these models are indicated where necessary. Available Models Note: Installation of this product should be made by a qualified technician and should conform to all local codes. -
Page 3: How To Open The Gimbal Cover
How to Open the Gimbal Cover Assembly & Mounting Accessories EasyView Dome Cameras have vari-focal lens integrated inside the Gimbal. If you • Torx Wrench - For Vandalproof Domes require to make focal/focus adjustments, the Gimbal cover needs to be removed Model #: T20 Length: 2 temporarily. -
Page 4: Dimensions
Dimensions Parts Name and Descriptions (UNIT: mm) 1. Lens lush Mount 2. Power Input Connector 12VDC/24VAC Dual Voltage 3. Video Output Connector - BNC 4. Service Monitor Output Connector Use Cable CA-SMC30. 5. Camera Control Board 6. Safety Wire Surf r r ace Mount 7. -
Page 5: Base Installations
Base Installations Mounting Housings to Electrical Junction Boxes 1. Remove dome cover by loosening 3 screws. For indoor domes, use standard Philips Either flush mount or surface mount application, pre-drilled mounting holes on EasyView screw driver. For vandalproof domes, use Torx wrench provided with the package. Domes accommodate various electrical junction boxes, making installation easy and less time consuming. -
Page 6: Connections
On WD Series, use the OSD Menu using the mini joystick board. (Part# CA-SMC30) is required. Contact your distributor or NUVICO Sales Department Replace the Gimbal cover back to the Gimbal base. - Page 7 Dip Switch Adjustments WD Series OSD Menu Instructions DC Level Button WD Series High Resolution • WDR • Day/Night RIGHT key Service Monitor Dip Switches UP key Output CENTER key DOWN key H Series High Resolution LEFT key DIP Switch Functions 2nd VIDEO DC Auto Iris Lens Electronic Iris...
- Page 8 WD Series OSD Menu Instructions WD Series OSD Menu Instructions Menu & Setting Details OSD Menu Control CENTER KEY - Used to access menu mode, Also used to confirm the setting Main Menu UP / DOWN KEY - Used to choose the desired menu selection. •DISPLAY ID : ON or OFF SETUP ID LEFT / RIGHT KEY - Used to choose the desired menu feature adjustment.
- Page 9 WD Series OSD Menu Instructions WD Series OSD Menu Instructions F. LOW LIGHT Main Menu • SLOW SHUTTER : Control Image brightness by adjusting the shutter speed A. SETUP ID - AGC : shutter speed setting( Range 28 to 48) - MAX FIELD : Shutter open from Min.
-
Page 10: 3-Axis Gimbal Adjustments
3-Axis Gimbal Adjustments Specifications H Series The Gimbal mechanism yields maximum rotation and placement as shown below. Indoor Color Dome Cameras CD-H266 CD-H3895 CD-H922 Vandalproof Color Dome Cameras 355º CV-H266 CV-H3895 CV-H922 Item H Series Video Formats NTSC Image Sensor 1/3"... -
Page 11: Sd Series Specifications
Specifications Specifications SD Series WD Series Indoor Color Dome Cameras Indoor Color Dome Cameras CD-SD266 CD-SD3895 CD-SD922 CD-SD3895-L CD-WD266 CD-WD3895 CD-WD922 Vandalproof Color Dome Cameras Vandalproof Color Dome Cameras CV-SD266 CV-SD3895 CV-SD922 CV-SD3895-L CV-WD266 CV-WD3895 CV-WD922 Item SD Series Item WD Series Video Formats Video Formats... -
Page 12: Fan & Heater Specification
Fan & Heater Specification Indoor & Vandalproof Dome Cameras Power Input 24VAC Power Consumption (Heater) Power Consumption (Fan) 0.7W Heater ON at 41ºF (5ºC) Heater OFF at 59ºF (15ºC) Fan ON 24 Hours Note: For Fan and Heater operation, 24VAC power input is required. Current model does not support 12VDC operation.
