  • Page 2: Warning And Caution

    NUVICO. • NUVICO makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or malfunction of the cameras, peripheral devices, or unapproved/ unsupported devices.

  • Page 3: Fcc Compliance Statement

        FCC Compliance Statement FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.

  • Page 4: Important Safeguards

    Important Safeguards • Read these instructions. • Heed all warnings. • Follow all instructions. • Do not use this equipment near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

  • Page 5: Table Of Contents

        Table of Contents 1. Introduction ................. 7   About This Manual ................... 7   1.1 Key features ....................7   1.2 Content Verification ................... 8   1.3 EasyTrak™ Mini PTZ Dome Camera Dimensions ........9   2. Installation and Configuration ........... 10  ...
  • Page 6 3.9 Privacy Zone .................... 41   3.10 Camera Menu ..................42   3.11 Dome Setup ................... 47   3.12 Function Run ..................57   3.13 Factory Setup ..................58   Troubleshooting Tips ............59          ...

  • Page 7: Introduction

        1. Introduction About This Manual Thank you for purchasing our EasyTrak™ Mini PTZ speed dome camera. This full-featured camera comes equipped with a high resolution ¼” Interline transfer CCD imager, which enhances low light sensitivity and provides crystal clear pictures even in challenging lighting environments.

  • Page 8: Content Verification

    1. Introduction 1.2 Content Verification Before installing the camera, please make sure that all of the following items are included in the box. EasyTrak™ Mini PTZ Dome Camera ....1 Instruction Manual (This document) ....1 Mounting Template Sheet ......1 Mounting Bracket ........1 Safety Lanyard ........1 Mounting Kits...

  • Page 9: Easytrak™ Mini Ptz Dome Camera Dimensions

        1. Introduction 1.3 EasyTrak™ Mini PTZ Dome Camera Dimensions        ...

  • Page 10: Installation And Configuration

    2. Installation and Configuration 2.1 Installation The dome camera is for use in surface or pendent mounting applications and the mounting member must be capable of supporting loads of up to 3.3lb (1.5kg). (Pendent mounting must use pendent mount accessory.) The dome camera’s mounting bracket should be attached to a structural object, such as ply wood, wall stud or ceiling rafter that supports the weight of the dome camera.

  • Page 11: Locking Dome Camera

        2. Installation and Configuration 2.2 Locking Dome Camera A. Make screw holes on the ceiling using the supplied mounting Template Sheet (Figure A). B. Fix the Mounting Bracket using Anchors(4x) and Mounting Screws(4x) to the ceiling (Figure B). C.
  • Page 12 2. Installation and Configuration CAUTION 1: • Before installing mounting bracket to surface, pre-adjust the four mounting screws "A” (Figure F) on the base of the dome camera to best match the mounting bracket locked position. • Unscrew the locking screw on the side of the dome's base and fit the tab of the mounting bracket into the locking slot.

  • Page 13: Typical System Configuration

        2. Installation and Configuration 2.3.1 Typical System Configuration Additional Controller Keyboard and a variety of external switching devices such as Multiplexers (MUXes) and Digital Video Recorders (DVRs) may be incorporated to accommodate the needs from a small to a large surveillance/security system. Figure 1: Illustrates Sample Installation Configuration.

  • Page 14: Basic Configuration Of Easytrak™ Mini Ptz Dome System

    2. Installation and Configuration 2.3.2 Basic Configuration of EasyTrak™ Mini PTZ Dome System Figure 2 Illustrates the Basic Installation Configuration.        ...

  • Page 15: Connecting The Easytrak™ Mini Ptz Dome Directly To The Dvr

        2. Installation and Configuration 2.3.3 Connecting the EasyTrak™ Mini PTZ Dome Directly to the Locate the RS-422 Rx+ & Rx- conductor wire from the EasyTrak™ Mini PTZ dome camera. Connect the RS-485 Tx(+)/ Tx(-) of the DVR into Rx(+)/Rx(-) of the Mini PTZ dome camera.    ...

  • Page 16: Connecting The Easytrak™ Mini Ptz Dome Into The Controller Keyboard Via J-Box

    2. Installation and Configuration 2.3.4 Connecting the EasyTrak™ Mini PTZ Dome into the Controller Keyboard via J-box        ...

  • Page 17: Connecting The Easytrak™ Mini Ptz Dome To The Dvr Via J-Box

        2. Installation and Configuration 2.3.5 Connecting the EasyTrak™ Mini PTZ Dome to the DVR via J-box Illustration below shows connecting EasyTrak™ Mini PTZ dome & DVR into the Controller Keyboard.        ...

  • Page 18: Dip Switch Layout Diagram

    2. Installation and Configuration 2.4 Dip Switch Layout Diagram Illustration – Layout of DIP Switches NOTE: Open the switch cover (position “a”) and change the setting of DIP switches. The cover should be closed after setting DIP switches. 2.4.1 Setting Dome Camera Termination The device which is connected at end of line, whether it is a dome camera or keyboard controller, must have the cable for communication terminated by setting the appropriate DIP switch.
  • Page 19     2. Installation and Configuration DOME ID (16) (32) (64) (128) For ID 33~255, please contact our technical support.        ...

  • Page 20: Setting Dome Camera Protocol And Video

    Europe, Middle East, Africa: PAL You can set Protocol with dip switch D2, D3 and D4 in S2. Protocol DEFAULT: NUVICO, Pelco-P, Pelco-D Pelco-P, Pelco-D Only You can set Baud Rate with dip switch D5 and D6 in S2. Baud Rate...

  • Page 21: Connections

        2. Installation and Configuration 2.5 Connections • Connecting to the RS485 The dome camera can be controlled remotely by an external device or control system, such as a control keyboard, using RS485 half-duplex serial communications signals. • Connecting Video out connector Connect the video out (BNC) connector to the monitor or video input.

  • Page 22: Power On & Boot-Up Sequence

    2. Installation and Configuration 2.6 Power On & Boot-Up Sequence When the EasyTrak™ Mini PTZ camera is powered up, it will automatically start the boot-up sequence. The following information is displayed once the boot-up sequence is complete. PRESET TITLE AREA TITLE STATUS OF FOCUS FUNCTION AF AE...

  • Page 23: Program And Operation

    Exit the changing angle mode. IRIS Close Escape (EXIT) IMPORTANT: This section covers the programming of EasyTrak™ PTZ dome camera when directly connected to the NUVICO Controller Keyboard. For programming using only the DVR, please refer to your DVR manual.      ...

  • Page 24: Accessing The On-Screen Dome Menu

    3. Program and Operation 3.1 Accessing the On-Screen Dome Menu You can call up the On-screen menu utility on your monitor by pressing the MENU key on the keyboard controller, the following On-screen menu utility will appear: DOME MENU AUTO SCAN PRESET TOUR PATTERN...

  • Page 25: Auto Scan (Shortcut: Scan)

        3. Program and Operation 3.2 Auto Scan (Shortcut: SCAN) The Auto Scan supports up to 5 programmed angles at user-programmable speeds. Follow these steps to program the Auto Scan: AUTO SCAN SETUP NUMBER : 01 TITLE : A01 MODE : NORMAL SPEED...
  • Page 26 3. Program and Operation 1. Press the SCAN key to enter the Auto Scan menu directly. Or press the MENU key to display the main menu on the monitor. Scroll to Auto Scan and push the Joystick to the right. 2.
  • Page 27     3. Program and Operation 7. Select “END ANGLE”. Hold down the SHIFT key while moving the Joystick to select the end position. The end position angle should be larger than start position. Release the SHIFT key to complete the selection of the end position. Or press the IRIS Open key then the “CTRL”...
  • Page 28 3. Program and Operation To set the position using the Preset position: a. Before entering the Auto Scan menu, select a Preset position as a starting point for Auto Scan. Example: 2 + PRST key and do step 1 to 5 from the above. In step 6, just press the SHIFT key at the start angle position, the current position will be displayed as a start position.

  • Page 29: Preset (Shortcut: Prst)

        3. Program and Operation 3.3 Preset (Shortcut: PRST) If you need to view specific places routinely, you should program Presets. A Preset is a programmed video scene with automatic pan, tilt, zoom, focus, motion and AE settings. Once programmed, placing the number position and pressing the PRST key on your controller calls up that Preset automatically.
  • Page 30 3. Program and Operation Follow steps below to store the Preset positions: 1. Press the PRST key to enter the Preset menu directly. Or press the MENU key to display the main menu on the monitor. Scroll to Preset and push the Joystick to the right. 2.
  • Page 31     3. Program and Operation Select “MOTION SETUP” and pushing the Joystick to the left or right. Then the MOTION setup displays. MOTION SETUP SENSITIVITY : 07 POSITION : ALL DELAY : 00 SEC OUTPUT : OFF HOLD TIME : 03 SEC EXIT (ESC TO EXIT) Set SENSITIVITY...

  • Page 32: Pan Tilt

    3. Program and Operation The position, which is marked with the *, already has the Preset view assigned. To review the stored Preset, press the PRST key on the *. The camera will show the stored Preset scene. PRESET AREA SETUP (CTRL KEY) NUMBER 001 TILT...

  • Page 33: Tour (Shortcut: Tour)

        3. Program and Operation 3.5 Tour (Shortcut: TOUR) There are 4 programmable Tours. Each Tour consists of up to 42 Preset positions, Patterns, Scans or other Tours (second-level). Using second-level Tours, it can be expanded to over 150 functions in a single Tour. TOUR SETUP NUMBER TITLE...
  • Page 34 3. Program and Operation Follow the steps below to program the Tours: 1. Press the MENU key to display the main menu on the monitor. Scroll to Tour and push the Joystick to the right to enter the Tour menu. Or just press the TOUR key on the keyboard.
  • Page 35     3. Program and Operation To change the dwell time of the Preset in the Tour: 1. Use the Joystick to move the cursor to a stored Preset position. 2. By pressing the PRST key, the camera will move to the stored Preset view and the cursor moves to the dwell time field.

  • Page 36: Pattern (Shortcut: Ptrn)

    3. Program and Operation 3.6 Pattern (Shortcut: PTRN) The Pattern feature records user control of the selected dome camera. Up to 4 Patterns can be stored and played back by pressing No. + PTRN keys subsequently. PATTERN SETUP (CTRL KEY) TITLE PERCENT 01 :...
  • Page 37     3. Program and Operation NOTE: Press the HOME key at any programmed position to delete the Pattern. NOTE: If Pattern recording time reaches 200 seconds, it will automatically stop for a moment. Press the PTRN key on the title field to display with the small OSD. Then the screen will show as below.

  • Page 38: Alarm

    3. Program and Operation 3.7 Alarm ALARM SETUP NO PRI FUN IN OUT HLD LATCH 001 NC ALARM OUT SETUP SAVE AND EXIT(ESC TO CANCEL) : alarm input number : The lower number has higher priority. (1 fixed) PRI(Priority) : Stored function number to be called by alarm. FUN(Function) : NO/NC –...

  • Page 39: Area Title

        3. Program and Operation 3.8 Area Title Enter a specific name on programmed angle between START and END. For the screen below, when the camera points at an angle between 124.3° (PAN), 30.7° (TILT) to 359.5° (PAN), 45.4° (TILT), ABC will be displayed on the screen. AREA TITLE SETUP NUMBER : 01...
  • Page 40 3. Program and Operation 1. Select “NUMBER” and set the desired number by pushing the Joystick to the left or right. 2. To edit the “TITLE”, follow the procedure of the Auto Scan above to edit titles. 3. Select “START ANGLE”. Hold down the SHIFT key while selecting the start position using the Joystick.

  • Page 41: Privacy Zone

        3. Program and Operation 3.9 Privacy Zone Hide up to 4 unwanted scenes in a camera. PRIVACY ZONE SETUP (CTRL KEY) TITLE METHOD 01 ABC BLOCK 02 DEF V.OFF ---- ---- SAVE AND EXIT(ESC TO CANCEL) 1. Place the cursor at the title field. 2.

  • Page 42: Camera Menu

    3. Program and Operation 3.10 Camera Menu CAMERA SETUP FOCUS CONTROL WB CONTROL AE CONTROL DNR CONTROL LINE LOCK CONTROL SHARPNESS : 07 RESOLUTION : MID DIGITAL ZOOM : OFF IMAGE FLIP : OFF PRESET FREEZE : OFF SAVE AND EXIT(ESC TO CANCEL) The higher the value, the more edges in the picture will be SHARPNESS enhanced.
  • Page 43     3. Program and Operation • FOCUS CONTROL FOCUS SETUP MODE : ONE PUSH FOCUS LIMIT : 1.0M SAVE AND EXIT(ESC TO CANCEL) AUTO / MANUAL / ONE PUSH / CONSTANT MANUAL MODE Use “ONE PUSH” in normal use. This distance is approximate value and the focus operate from the FOCUS LIMIT setting value.
  • Page 44 3. Program and Operation • AE CONTROL AE SETUP MODE : MANUAL DSS LIMIT : OFF GAIN : MIN BRIGHT : 003 SHUTTER : 1/50 FLICKERLESS : --- BACK LIGHT : OFF : --- WDR LEVEL : --- NIGHT SHOT : AUTO SAVE AND EXIT(ESC TO CANCEL) AE1 / AE2 / SHUTTER PRIO / MANUAL...
  • Page 45     3. Program and Operation The NIGHT SHOT option removes the IR cutoff filter of the camera and makes the camera sensitive to infrared. Camera goes in to B&W mode at low light. AUTO Camera is in B&W all the time. Camera is in Color all the time.
  • Page 46 3. Program and Operation • DNR CONTROL DNR CONTROL SETUP 2DNR(1) : OFF 3DNR(1) : OFF 2DNR(2) : OFF 3DNR(2) : OFF SAVE AND EXIT(ESC TO CANCEL) Select 2D noise reduction level (1 ~ 7 / OFF) 2DNR(1), 2DNR(2) Select 3D noise reduction level (1 ~ 31 / OFF) 3DNR(1), 3DNR(2) NOTE: DNR(1) applies to when the motor is stopped.

  • Page 47: Dome Setup

        3. Program and Operation 3.11 Dome Setup CONFIGURATION MENU LANGUAGE : ENGLISH HOME FUNCTION SETUP OSD DISPLAY VIEW ANGLE SETUP INITIALIZE DATA ORIGIN OFFSET DOME RESET SYSTEM MENU SYSTEM INFORMATION SAVE AND EXIT(ESC TO CANCEL) • LANGUAGE SETUP LANGUAGE : Select the language you want.
  • Page 48 3. Program and Operation The Home function can be set so that the camera automatically goes to Tour, Pattern, Auto Scan, Preset after the keyboard controller has been idle for certain amount of time. For example, if the controller is idle for 120 seconds, the camera goes to Preset 1. Follow these steps to program the Home position: 1.
  • Page 49     3. Program and Operation • OSD DISPLAY OSD DISPLAY SETUP CAMERA TITLE : DOMEID VIEW DIRECTION : OFF DOME OSD : ON AREA TITLE : OFF PRESET TITLE : CONSTANT FOCUS EXPOSURE : ON OSD POSITION SETUP SAVE AND EXIT(ESC TO CANCEL) : up to 6 characters.
  • Page 50 3. Program and Operation • OSD POSITION SETUP Select the OSD option with the Joystick up and down, press the SHIFT key and adjust the position by the Joystick. (AREA TITLE) (AF AE) (FUNC TITLE (CTRL KEY TO MOVE) SAVE AND EXIT(ESC TO CANCEL) (ALARM MESSAGE) DOMEID…XXX XXX.X XXX.X...
  • Page 51     3. Program and Operation ON: When this option is enabled, the range of the tilt angle will be limited to 10 degree. This can prevent from obstruction or bad focus problem caused by the horizontal line of the semi sphere in the bubble. OFF: When this option is disabled, the range of the tilt angle will not be limited.

  • Page 52: Initialize Data

    3. Program and Operation • INITIALIZE DATA INITIALIZE DATA FACTORY DEFAULT ERASE PROGRAMMED DATA PRESET FOCUS DEFAULT EXIT(ESC TO EXIT) • FACTORY DEFAULT Select “FACTORY DEFAULT” to initialize the Data. FACTORY DEFAULT ARE YOU SURE ? CANCEL • ERASE PROGRAMMED DATA Erase all stored data from the Flash-ROM of the selected camera.
  • Page 53     3. Program and Operation • PRESET FOCUS DEFAULT This menu set the default mode of the focus when you save the Preset. PRESET FOCUS DEFAULT FOCUS : AUTO SAVE AND EXIT(ESC TO CANCEL) : AUTO / MANUAL / ONE PUSH FOCUS •...
  • Page 54 3. Program and Operation • SYSTEM MENU SYSTEM MENU MOTOR SETUP PASSWORD EDIT ORIGIN CHECK CALIBRATION : ON PASSWORD ENABLE : OFF MENU TIME OUT : OFF BLINK CURSOR : ON DOME ANSWER : ON SAVE AND EXIT(ESC TO CANCEL) : ON(Auto origin check) / OFF CALIBRATION : ON(requires the password to enter menu) / OFF...
  • Page 55     3. Program and Operation : ON / OFF PROPOTIONAL P/T : SLOW / NORMAL / TURBO P/T MODE SLOW MAXIMUM SPEED : 40˚/second NORMAL MAXIMUM SPEED : 90˚/second TURBO MAXIMUM SPEED : 380˚/second • PASSWORD EDIT PASSWORD EDIT SETUP (CTRL KEY) INPUT PASSWORD PASSWORD :...
  • Page 56 3. Program and Operation • ORIGIN CHECK When you find the wrong position of the camera during operation, execute this origin check and the dome camera will arrange to the right position after the origin check operation. ORIGIN CHECK ARE YOU SURE ? CANCEL Pressing 151 + ON keys will execute the origin check.

  • Page 57: Function Run

        3. Program and Operation 3.12 Function Run This Function Run menu allows you to execute the function when you use a keyboard or a DVR without the function keys (Preset, Pattern, Tour and Scan). FUNCTION RUN SETUP (CTRL KEY) PRESET : --- PATTERN...

  • Page 58: Factory Setup

    3. Program and Operation ALARM OUT SETUP 1 MIN EXIT(ESC TO EXIT) You press the SHIFT or IRIS Open key then that alarm out operates during the setting time only. 3.13 Factory Setup FACTORY SETUP TOUR DWELL TIME : 03 SEC ANSWER DELAY : 03 SEC SAVE AND EXIT(ESC TO CANCEL)

  • Page 59: Troubleshooting Tips

        Troubleshooting Tips If problems occur, verify the installation of the camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. Problem Possible Solution Verify that power is connected to all pieces of...
