J11 – External clock source enable
The xPC560S Mini-Module contains a footprint for an SMA connector, which
can be used to provide an external clock source to the system.
Jumper Setting
On
Off (default)
36
Effect
The MPC560xS "EXTAL" signal is connected to the
SMA connector on the xPC560S Mini‐Module
The SMA connector on the xPC560S Mini‐Module is
disconnected from the processor
xPC560S EVB User Manual
