On (default)
Off
26
The potentiometer wiper terminal is connected to
the "PB0" pin on the MPC560xS processor.
The potentiometer wiper terminal is left
disconnected.
Figure 3-9: Potentiometer schematic
xPC560S EVB User Manual
