P&E Microcomputer Systems XPC560S EVB User Manual page 23

J20 – LIN2 master selection
Jumper Setting
On
Off (default)
J21 – LIN2 pin1 configuration
Jumper Setting
On
Off (default)
J29 – LIN2/SCI TxD selection
Controls whether the TxD pin on LIN2 or SCI is connected to the default I/O
pin on the MPC560xS processor.
Jumper Setting
1+2
2+3
xPC560S EVB User Manual
Effect
LIN2 is configured as a master node
LIN2 is configured as a slave node
Effect
Pin 1 of the LIN2 connector is connected to 12V
Pin 1 of the LIN2 connector is not connected to 12V
Effect
The LIN2 TxD pin is connected to the "PI6" pin on the
MPC560xS processor. This should be set if enabling
LIN2.
The SCI TxD pin is connected to the "PI6" pin on the
MPC560xS processor.
19
