SCI
One SCI interface is available on the xPC56XXMB.
J16 – SCI TxD Enable
Jumper Setting
On (default)
Off
J17 – SCI RxD Enable
Jumper Setting
On (default)
Off
J27 – LIN1/SCI TxD selection
Controls whether the TxD pin on LIN1 or SCI is connected to the default I/O
pin on the MPC560xS processor.
Jumper Setting
1+2
xPC560S EVB User Manual
Effect
Enables SCI transmit
Disables SCI transmit
Effect
Enables SCI receive
Disables SCI receive
Effect
The LIN1 TxD pin is connected to the "PB3" pin on the
MPC560xS processor.
21
