J27 – LIN1/SCI TxD selection
Controls whether the TxD pin on LIN1 or SCI is connected to the default I/O
pin on the MPC560xS processor.
Jumper Setting
1+2
2+3
J28 – LIN1/SCI RxD selection
Controls whether the RxD pin on LIN1 or SCI is connected to the default I/O
pin on the MPC560xS processor.
Jumper Setting
1+2
2+3
xPC560S EVB User Manual
Pin 1 of the LIN1 connector is connected to 12V
Pin 1 of the LIN1 connector is not connected to 12V
Effect
The LIN1 TxD pin is connected to the "PB3" pin on
the MPC560xS processor. This should be set if
enabling LIN1.
The SCI TxD pin is connected to the "PB3" pin on the
MPC560xS processor.
Effect
The LIN1 RxD pin is connected to the "PB2" pin on
the MPC560xS processor. This should be set if
enabling LIN1.
The SCI RxD pin is connected to the "PB2" pin on
the MPC560xS processor.
17
