power pins.
Jumper Setting
1+2 (default)
2+3
J16 – VDDR Voltage Selection
Sets the voltage level on the MPC560xS "VDD_IO_A" power pin.
Jumper Setting
1+2 (default)
2+3
J25 – VDDE_E Voltage Selection
Sets the voltage level on the MPC560xS "VDD_IO_D" power pin.
Jumper Setting
1+2 (default)
32
Effect
MPC560xS "VDD_IO_B" and "VDD_IO_C" pins are
powered by 5V (J14 must be ON)
MPC560xS "VDD_IO_B" and "VDD_IO_C" pins are
powered by 3.3V (J18 must be ON)
Effect
MPC560xS "VDD_IO_A" is powered by 5V (J14 must
be ON)
MPC560xS "VDD_IO_A" is powered by 3.3V (J18
must be ON)
Effect
MPC560xS "VDD_IO_D" is powered by 5V (J14 must
be ON)
xPC560S EVB User Manual
