4 xPC560SADPT144S HARDWARE & JUMPER SETTINGS
4.1

Boot Configuration

The following jumpers affect the operation of the processor as it initially
comes out of the reset state:
J7 – FABM Configuration
Controls whether the processor boots from internal FLASH or from a serial
interface (CAN, SCI)
Jumper Setting
1+2
2+3 (default)
J8 – ABS0 Configuration
If J7 is configured for serial boot mode, this jumper selects between UART or
CAN. If J7 is configured for internal boot mode, this jumper has no effect.
Jumper Setting
1+2
2+3 (default)
28
Effect
The MPC560xS processor uses serial boot mode
The MPC560xS processor uses internal boot mode
Effect
The MPC560xS processor uses the CAN interface for
serial boot mode
The MPC560xS processor uses the UART interface for
serial boot mode
