J19 – VDDMA Voltage Selection
Sets the voltage level on the MPC560xS "VDD_SMD_A" power pin.
Jumper Setting
1+2 (default)
2+3
J24 – VDDE_C Voltage Selection
Sets the voltage level on the MPC560xS "VDD_IO_F" power pin.
Jumper Setting
1+2 (default)
2+3
J23 – VDDE_B Voltage Selection
Sets the voltage level on the MPC560xS "VDD_IO_E" power pin.
Jumper Setting
1+2 (default)
34
Effect
MPC560xS "VDD_SMD_A" is powered by 5V (J14
must be ON)
MPC560xS "VDD_SMD_A" is powered by 3.3V (J18
must be ON)
Effect
MPC560xS "VDD_IO_F" is powered by 5V (J14 must
be ON)
MPC560xS "VDD_IO_F" is powered by 3.3V (J18 must
be ON)
Effect
MPC560xS "VDD_IO_E" is powered by 5V (J14 must
be ON)
xPC560S EVB User Manual
