2+3
J26 – VDDA Voltage Selection
Sets the voltage level on the MPC560xS "VDD_ADC" power pin.
Jumper Setting
1+2 (default)
2+3
4.3

System Clock Configuration

The xPC560S Mini-Modules support the usage of crystal clock sources as
well as external clock sources.
J10 – Crystal clock source enable
Both of the jumpers below need to be installed to enable the crystal clock
source.
Jumper Setting
1+2 (default)
3+4 (default)
xPC560S EVB User Manual
MPC560xS "VDD_IO_E" is powered by 3.3V (J18
must be ON)
Effect
MPC560xS "VDD_ADC" is powered by 5V (J14 must
be ON)
MPC560xS "VDD_ADC" is powered by 3.3V (J18
must be ON)
Effect
The MPC560xS "EXTAL" signal is connected to the
crystal clock source on the xPC560S Mini‐Module
The MPC560xS "XTAL" signal is connected to the
crystal clock source on the xPC560S Mini‐Module
35
