Simplex 4100U Operation Reference page 7

Product Selection (Continued)
Remote InfoAlarm Command Center Control Assembly with Cabinet for Surface Mounting
Model Number/Cabinet Color
Red Beige
4100-9401 4100-9402
4100-9421 4100-9422
4100-9441 4100-9442
Remote InfoAlarm Command Center Front View
Remote InfoAlarm Command Center Mounting Reference
8"
(203 mm)
NOTE: Bring wiring through back of box; do not use cabinet bottom;
Application Type Listing
English UL & ULC
French/Canada
International
Fire Priority 2
Alarm Alarm Supervisory
Fire Alarm Priority 2
Ack Ack
ALARMS
Box and door width = 20-1/2" (521 mm)
16" (406 mm)
RUI Communications
wiring terminals
24 VDC power input
wiring terminals
refer to Installation Instructions shipped with assembly
Description
Remote InfoAlarm Command Center with cabinet; for
surface mounting; includes mounting box and door
ULC assembly with glass insert; uses RUI communications;
requires external 24 VDC system voltage; see illustrations
UL
below and Installation Instructions 579-687 for details
Page Up
Previous
Next
Page Dn
System System Alarm AC
Trouble Silenced Power
Supv Trouble Alarm System
Ack Ack Silence Reset
WARNINGS
Transponder
Interface Card
(TIC)
7
A B C D E F G H I
ZONE SIG AUX
1 2 3
J K L M N O P Q R
FB IO IDNet
4 5 6
S T U V W X Y Z /
P A L
7 8 9
'SP' ( ) , # :
NET ADDR
C/Exit
0
Menu Enter
Depth 2-3/4"
(70 mm)
2" (51 mm)
3/4" (19 mm)
conduit
13-1/16"
(332 mm)
S4100-0045-4 11/2007
see
note
