Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPSConnector/Header Locations and Pin-outs
cards that need them. Available power to each of these connectors is limited by the amount of
power provided by the power supply and the total power draw for the rest of the system. A
power budget for the complete system should be performed to determine how much
supplemental power is available to support any high power add-in cards.
Each connector is labeled as "OPT_12V_PWR" on the server board. The following table
provides the pin-out for both connectors.

Table 32. Add-in Slot Power Pin-input ("OPT_12V_PWR")

6.2

Front Panel Header and Connectors

The server board includes several connectors that provide various possible front panel options.
This section provides a functional description and pin-out for each connector.
6.2.1

Front Panel Header

Included on the left edge of the server board is a 30-pin header consists of a 24-pin SSI
compatible front panel header and a 4-pin header to support optional NIC3/4 LEDs. The 24-pin
SSI front panel header provides various front panel features including:

Power/Sleep Button

System ID Button

NMI Button

NIC Activity LEDs

Hard Drive Activity LEDs

System Status LED

System ID LED
The following table provides the pin-out for this 30-pin header.
Pin
1 P3V3_AUX
3 Key
5 FP_PWR_LED_BUF_N
7 P3V3
9 LED_HDD_ACTIVITY_N
11 FP_PWR_BTN_N
13 GND
15 FP_RST_BTN_N
17 GND
19 FP_ID_BTN_N
21 PU_FM_SIO_TEMP_SENSOR
23 FP_NMI_BTN_N
25 <Empty Pin>
27 LED_NIC_LINK2_ACT_FP_N
Revision 1.1
Pin Signal Name
1 GND
2 GND

Table 33. Front Panel Header Pin-out

Signal name Pin
10
12
14
16
18
20
22
24
26
28
Intel order number G34153-003
Pin Signal Name
3 +12V
4 +12V
2 P3V3_AUX
4 P5V_STBY
6 FP_ID_LED_BUF_N
8 FP_LED_STATUS_GREEN_BUF_N
FP_LED_STATUS_AMBER_BUF_N
LED_NIC_LINK0_ACT_BUF_N
LED_NIC_LINK0_LNKUP_BUF_N
SMB_SENSOR_3V3STBY_DATA
SMB_SENSOR_3V3STBY_CLK
FP_CHASSIS_INTRUSION
LED_NIC_LINK1_ACT_BUF_N
LED_NIC_LINK1_LNKUP_BUF_N
<Empty Pin>
LED_NIC_LINK3_ACT_FP_N
Signal name
91
