CHASSIS SPECIFICATIONS

Front suspension
Shock absorber travel
Optional spring
Rear suspension
Shock absorber travel
Optional spring
Front wheel
Type
Rim size
Rim material
Rim runout limit
Rear wheel
Type
Rim size
Rim material
Rim runout limit
Drive chain
Type/ manufacturer
Link quantity
Drive chain slack
Front drum brake
Type
Brake drum inside diameter
Lining thickness
Shoe spring free length
Item
radial
lateral
radial
lateral
CHASSIS SPECIFICATIONS
35 mm (1.38 in)
No
40 mm (1.57 in)
No
Panel wheel
8 x 5.5 AT
Steel
----
----
Panel wheel
8 x 7 AT
Steel
----
----
#520/ KMC
66
10 mm~25 mm (0.39 in~0.98 in)
Leading, trailing
85.0 mm (3.35 in)
3.0 mm (0.12 in)
46.3 mm (1.82 in)
2 - 11
SPEC SPEC
Standard Limit
----
----
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
----
86.0 mm
(3.39 in)
1.5 mm
(0.06 in)
----
