Sist. Electrónico - Schaerer Opal Spare Parts Catalog

EK Opal / Siena / Siena 2
Pos. Art. Nr. Bezeichnung
Part No.
No. Art.
Art. nº.
1 062170 Klixon 140°C Pumpe
2 071692 Steuerung 2004 Siena Ersatz
071699 Steuerung Piccolo 2004
062200 Steuerung Opal 100VAC Tank
062201 Steuerung Opal 200-240VAC
3 062230 Microschalter mit Rolle
4 062077 Taptite Linsenschraube M4x12
5 062799 Podest Deckel
6 062210 Ringkerntrafo 230VAC 50-
60Hz/12VAC
062800 Ringkerntrafo 200VAC 50-
60Hz/12VAC
062213 Ringkerntrafo 240VAC 50-
60Hz/12VAC
062214 Ringkerntrafo 130VAC 50-
60Hz/12VAC
062211 Ringkerntrafo 120VAC 50-
60Hz/12VAC
062215 Ringkerntrafo 110VAC 50-
60Hz/12VAC
062212 Ringkerntrafo 100VAC 50-
60Hz/12VAC
7 062205 Netzschalter
8 062206 Halter Schalter Gestell
9 062208 Schalterbetätigung anthrazit
062251 Schalterbetätigung schwarz
062777 Schalterbetätigung grau
062781 Schalterbetätigung silber
10 062915 Frontpanel kompl. anthrazit
062917 Frontpanel kompl. schwarz
062921 Frontpanel kompl. silber
11 062235 Reedsensor
12 062250 Isolation Steuerung
13 062829 Standardblende 5 Produkte
062840 Self-Blende 2-Produkte
062841 Self-Blende 3-Produkte
062842 Self-Blende 4-Produkte
14 071547 Feder Erdung Panel
17 062562 Mikroschalter ohne Rolle
(wasserdicht)
18 062510 Mikroschalter ohne Rolle
21 071089 Printträger mit Lüfter
22 062074 Printträger Gestell li
23 062219 Lüfterblech
24 062220 Axiallüfter 24VDC
25 062245 PT-Schraube KA 22x12
26 1042024 Pan Head-Schraube M3x20
27 1220001 Sicherungsmutter A2 M3
Elektronik
Electronic
Electronique
Sist. electrónico
Designation
Klixon 140°C pump
Pc Board 2004 Siena
Pc Board Piccolo 2004
Pc Board Opal 100VAC tank
Pc Board Opal 200-240VAC
Microswitch with roller
Taptite oval head screw M4x12
Pedestal cover
Tor. trans. 230VAC 50-60Hz/12VAC Trsf.Tor. 230VCA 50-60Hz/12VCA
Tor. trans. 200VAC 50-60Hz/12VAC Trsf.Tor. 200VCA 50-60Hz/12VCA
Tor. trans. 240VAC 50-60Hz/12VAC Trsf.Tor. 240VCA 50-60Hz/12VCA
Tor. trans. 130VAC 50-60Hz/12VAC Trsf.Tor. 130VCA 50-60Hz/12VCA
Tor. trans. 120VAC 50-60Hz/12VAC Trsf.Tor. 120VCA 50-60Hz/12VCA
Tor. trans. 110VAC 50-60Hz/12VAC Trsf.Tor. 110VCA 50-60Hz/12VCA
Tor. trans. 100VAC 50-60Hz/12VAC Trsf.Tor. 100VCA 50-60Hz/12VCA
Main switch
Switch holder, frame
Switch actuator, anthracite
Switch actuator, black
Switch actuator, grey
Switch actuator, silver
Front panel, cmpl. anthracite
Front panel, cmpl. black
Front panel, cmpl. silver
Reed switch
Insulation, control unit
Standard restrictor 5 products
Restrictor slfsrv 2 products
Restrictor slfsrv 3 products
Restrictor slfsrv 4 products
Panel grounding spring
Microswitch without roll (waterproof) Microcontact sans galet
Microswitch without roll
PCB carrier with fan
PCB carrier frame, le
Fan sheet
Axial fan 24VDC
PT-screw KA 22x12
Pan head screw M3x20
Self-locking nut A2 M3
Catalogue des pièces detachées
Désignation
Klixon 140°C pompe
Commande 2004 Siena
Commande Piccolo 2004
Commande Opal 100VCA réservoir
Commande Opal 200-240 VCA
Microcontact avec galet
Vis tête bombée Taptite M4x12
Plateforme couvercle
Commutateur
Support interr. châssis
Commande interrupteur anthracite
Commande interrupteur noir
Commande interrupteur gris
Commande interrupteur argent
Panneau avant cpl. anthracite
Panneau avant cpl. noir
Panneau avant cpl. argent
Interr. Reed
Isolation commande
Obturateur standard 5 produits
Obturateut fss 2 produits
Obturateut fss 3 produits
Obturateut fss 4 produits
Ressort terre panneau
Microcontact sans galet
Support de circuit imprimé avec
ventilateur
Support de circuit imprimé châssis ga Bastidor izq. soporte impresora
Tôle pour ventilateur
Ventilateur axial 24 VCC
Vis autotaraud. KA 22x12
Vis à tête aplatie Pan-Head M3x20
Écrous autofreinés A2 M3
Ersatzteilkatalog
Spare Parts Catalogue
Catálogo de recambios
Denominación
Bomba caf. peq. 140°C Klixon
Control 2004 Siena
Control Piccolo 2004
Control Opal 100VAC depósito
Control Opal 200-240VAC
Microint. con rodillo
Tornillo alom. Taptite M4x12
Pedestal tapa
Tr.tor. 230VAC 50-60Hz/12VAC
Tr.tor. 200VAC 50-60Hz/12VAC
Tr.tor. 240VAC 50-60Hz/12VAC
Tr.tor. 130VAC 50-60Hz/12VAC
Tr.tor. 120VAC 50-60Hz/12VAC
Tr.tor. 110VAC 50-60Hz/12VAC
Tr.tor. 100VAC 50-60Hz/12VAC
Interruptor de red
Sop. interr. bastidor
Actuador interruptor antracita
Actuador interruptor negro
Actuador interruptor gris
Actuador interruptor plata
Panel frontal cpl. antracita
Panel frontal cpl. negro
Panel frontal cpl. plata
Sensor tipo Reed
Aislam. unidad de control
Diafragma estándar 5 productos
Diafragma SB 2 productos
Diafragma SB 3 productos
Diafragma SB 4 productos
Muelle panel tierra
Microint. s. rodillo
Microint. s. rodillo
Sop. c.imp y ventil.
Chapa ventil.
Ventil. axial 24VDC
Tornillo PT KA 22x12
Torn.cab. plana A2 M3x20
Tuerca autorr. A2 M3
01.02.2010
1-19
