Main Harness (N1) Wire Connection Guide

Main Harness Wiring Diagram

___
RED
N1/1
___
BLACK
N1/2
___
WHITE
N1/3
___
WHITE/BROWN
N1/4
___
BLACK/WHITE
N1/5
___
YELLOW
N1/6
___
GREEN
N1/7
___
BLUE
N1/8
___
N1/9 GRAY
___
N1/10
___
N1/11
ORANGE/GREEN
___
N1/12
ORANGE/BROWN

Main Harness Wiring Instructions

This guide describes in detail the connection of each wire. Some of the wires may have more than
one possible function. Please read carefully to ensure a thorough understanding of this unit.
N1/2 RED (+)12V constant power input
Before connecting this wire, remove the supplied fuse. Connect to the battery positive terminal, the
constant 12V supply to the ignition switch, or the fusebox.
N N O O T T E E : Always use a fuse within 12 inches of the point you obtain (+)12V. Do not use the 5 A fuse in
the harness for this purpose. This fuse protects the module itself.
N1/2 BLACK (-) chassis ground connection
Connect this wire to a clean, paint-free sheet metal location (driver kick panel) using a factory bolt
that DOES NOT have any vehicle component grounds attached to it. A screw should only be used
when in conjunction with a two-sided lock washer. Under dash brackets and door sheet metal are
not acceptable ground points. It is recommended that all security components be grounded at the
same location.
6
(+) Constant 12V Power Input (5A fused)
(-) Chassis Ground Input
(-) Parking Light Flash Input
(-) Turn Signal Indicator Light Input
(-) Domelight Input
(+) Ignition Status Output
(-) Door Status Output
(-) Trunk Status Output
(+) Trunk Release Output
©
Not Used
CAN-H Bus Wire
CAN-L Bus Wire
