APPENDIX Example CAN-IM –
VIPER 3000 Connections
CANIM
CANIM----VIPER
Connector/Pin
N1/1
RED
N1/2
BLACK
N1/3
WHITE
N1/4
WHITE/BROWN
N1/5
BLACK/WHITE
N1/6
YELLOW
N1/7
GREEN
N1/8
BLUE
N1/9
GRAY
N1/10
-
N1/11
ORANGE/GREEN
N1/12
ORANGE/BROWN
N2/1
GREEN/BLACK
N2/2
BLUE/BLACK
N2/3
BLUE
N2/4
GREEN/WHITE
N2/5
BLUE/WHITE
N2/6
BROWN
N2/7
GRAY
WHITE/BLUE
N3/1
VIOLET/BLACK
N3/2
WHITE/BLACK
N3/3
VIOLET/BLACK
N3/4
BROWN
N3/5
GRAY/BLACK
N3/6
ORANGE/BLACK
N3/7
RED/WHITE
N4/1
VIOLET/WHITE
N4/2
BLUE
N4/3
BROWN
20
Color
VIPER 3000
Connector/Pin
3000
H1/2
H1/5
H1/11
- (or H1/11)
H1/9
H1/4
H1/8
H1/7
-
-
-
-
H3/C
H3/F
H2/1
-
-
-
H2/2
H2/6
H2/5
-
-
H2/4
H2/3
H1/1
-
-
-
OBS
(Function)
+12V
0V
Parking Light
Turn Signal
Dome Light
Ignition Status
Door Status
Trunk Status
Trunk Release Output
-
CAN-H
CAN-L
Arm/Lock
Disarm/Unlock
Disarm/Unlock all doors
Arm Output
Disarm Output
Horn
Hood Status
Front Windows Down (CH4)
Rear Windows Down (CH5)
Sunroof
Headlight
Fuel door release (CH6)
Radio (RAO)
Trunk release (CH2)
RPM Output
Remote Start
Remote Start Shutdown
©
2005
Directed Electronics, Inc.
