561T PIN 1- BLUE
Recommendations for Channel Connections
The following channels of a VIPER system are recommended for connection with the CANIM
module:
➤ ➤
Channel 2 for "Trunk release" function
➤ ➤
Channel 3 for remote start
N N O O T T E E : : If a remote start module is not needed this channel can be used for "Headlight ON/OFF" func-
tion.
➤ ➤
Channel 4 for "Front windows down" function
➤ ➤
Channel 5 for "Rear windows down" function
➤ ➤
Channel 6 for "Fuel door release" function or "Headlight ON/OFF" function.
2005
©
Directed Electronics, Inc.
CLUTCH SWITCH
