LED will flash green rapidly (130msec ON, 130 msec OFF) as long as the programming is in
progress (aprox 1-sec), then it will illuminate green if the programming was successfully or red if
not, for aprox. 2.5-sec. During normal operation, the CAN-IM enters sleep mode if no input is
active or no CAN bus activity is detected for more than 4 sec. When the CAN-IM is in sleep mode
the LED is extinguished; when the CAN-IM is not in sleep mode the LED is illuminated green.
This is a method to verify proper operation of the CAN-IM module.
Finding the Wires in the Vehicle
The CAN-L wire (ORANGE/BROWN) and CAN-H wire (ORANGE/GREEN) can be found
easily in one of the following places:
➤ ➤
In the left A-pillar (left the driver's side under the fuses box) (T28/5 for CAN-L and T28/4 for
CAN-H).
➤ ➤
Under the steering column (connector T20d/15 – J527 for CAN-L and connector T20d/14 –
J527 for CAN-H).
In case that a Directed remote start module is used (VALET 561T) the following connections with
wires in the vehicle must be made:
➤ ➤
Pin 1 "Output to ignition circuit" (PINK) of the heavy gauge relay satellite connected to ignition
wire (BLACK) found under the steering column (connector T20d/17 – J527 )
N N O O T T E E : : In the new PASSAT the color of this wire is GREEN/GRAY.
➤ ➤
Pin 2 "Output to starter circuit" (PURPLE) of the heavy gauge relay satellite connected to starter
wire (RED/BLACK) found under the steering column (connector T20d/18 – J527 )
N N O O T T E E : : In the new PASSAT the color of this wire is RED/GRAY.
For the new PASSAT also the wire from the clutch switch must be connected (utilizing a relay for
polarity inversion) to Pin1 (BLUE) "Status output" of the 4-pin satellite (561T) in order for the
engine to start.
18
©
2005
Directed Electronics, Inc.
