Thermo Scientific FOCUS GC Instruction Manual page 334

Chapter 16
LAN Option Set-up
WARNING! If the connection is performed through hubs over a 10 Mbit/s network, it is
suggested that no more than 5 FOCUS GC LAN are connected on the same network
trunk. In the case of switched network, this warning can be ignored.
Alternative Configuration
An alternative to the direct setup of the FOCUS GC LAN, it is also possible to use
a management program designed for sites where multiple FOCUS GCs with LAN
option are available.In this case a specific program must be installed and used to
monitor, setup, or update each of the instruments connected.
The program to be installed is named DSSETUP.EXE, and available in the CD of
the Chrom-Card data system, as well as in the CD of this manual.
1. Run the installation setup program DSSETUP.EXE:
2. Deselect the check box COM Port Mapping Tools, since it is not required in
Please just follow the detailed route proposed step-by-step by the installation
program, and when finished, you can run the program. The first time after the
installation the program starts automatically.
3. From main menu select the Locate Server and the program will
334
the management of FOCUS GCs.
automatically search for all FOCUS GCs connected to the network.
Set-Up
Instruction Manual
