Technical data

14.1 Controller
Inputs/outputs
Rated voltage (system voltage)
Own consumption
Outputs R1, R2
Signal inputs/outputs
Signal inputs 1 ... 5
Signal output R
Signal outputs PWM R1, PWM R2
Hydraulic schemes (systems)
Quantity
Display
Type
Application conditions
Degree of protection
Protection class
Ambient temperature
Physical specifications
Dimensions L x W x H
Weight
Software class
Type of action
Type of fastening for permanently
connected cables
Degree of pollution
Ball pressure test temperature
Overvoltage category
Tab. 7: Technical controller data
50
Quantity
Type
Switching current
Voltage
Quantity
Type of signal inputs 1 ... 4
Type of signal input 5
S
Type
Max. contact load
Type
Max. load
115 ... 230 V~, 50/60 Hz
≤ 0.8 W, two Pt1000 temperature sensors connected
2
TRIAC
1.1 (1.1) A each
115 ... 230 V~, 50/60 Hz
5
Pt1000 (temperature acquisition)
• Pt1000 (temperature acquisition) or
• pulse water meter using 1 l/pulse, 10 l/pulse or
25 l/pulse (flow rate acquisition)
potential-free NO contact
1 (0) A, 24 V
PWM, 250 Hz, 11 V
10 mA
11
LCD display with backlighting
IP 22, DIN 40050 [without front panel: IP 20]
I
0 ... +50 °C, when wall-mounted
110 x 160 x 51 mm
350 g
A
type 1.Y
type X
2
casing pan: 125 °C
other casing parts: 75 °C
class II (2500 V)
