9.3.2 Back-up heating
Display
1)
Caution:
Standard pump: Set AC!
High-efficiency pump: Set HE!
External consumer (e.g. 230 V relay): Set AC pump type.
9.3.3 Solid fuel boiler
742.892 | 11.50
Performs temperature-dependent switching of an output for heating
a storage tank using an oil or gas burner. The function can be time
restricted.
Temperature control: If the temperature in the storage tank falls below
the value, then the external heating is switched on until the
T
on
perature is reached.
Time restriction: The function is executed when the current time lies
within one of 3 configurable time windows.
Characteristic
Activation
Output (external heating)
Pump type (R1, R2 only)
Pump characteristic (HE only)
Sensor input for readiness part of
the storage tank
Switch-on temperature T
Switch-off temperature T
Time restriction
Time window 1 start/end
Time window 2 start/end
Time window 3 start/end
Controls a pump in order to heat a storage tank using a solid fuel boiler.
The pump is switched on when all of the following conditions are satis-
fied at the same time:
• The temperature difference between the solid fuel boiler and the
storage tank exceeds
• The solid fuel boiler temperature lies above the min. solid fuel boiler
temperature.
• The storage tank temperature lies below the max. storage tank
temperature.
The pump is switched off when one the following conditions is satisfied:
• The temperature difference between the solid fuel boiler and the
storage tank drops below
• The solid fuel boiler temperature drops below the min. solid fuel
boiler temperature.
• The storage tank temperature reaches the max. storage tank tem-
perature.
Speed control of the pump can be activated as required. The loading
strategy of the speed control system attempts to regulate the tempera-
ture of the solid fuel boiler to match the control target that has been set.
The control target should be at least 10 K above the minimum tempera-
ture of the solid fuel boiler.
min.
on, oFF
free output R1/R2/R
AC, HE
AA, Ab, C (see page p. 16)
0 °C
on
T + 2 K
off on
on, oFF
0:00
0:00
0:00
.
T
diff on
.
T
diff off
tem-
T
off
Factory
max.
setting
oFF
S
1)
AC
1 ... 5
T – 2 K 55 °C
off
95 °C 60 °C
oFF
23:59 6:00/8:00
23:59 12:00/13:30
23:59 18:00/20:00
