SE7500CW2 Server Board Technical Product Specification
6.5.6.1 I/O Device Configuration Submenu
To access this submenu, select Advanced on the menu bar at the top of the screen and then I/O
Device Configuration.
Main Advanced
I/O Device Configuration
On Board Device
PCI Configuration
Server Menu
Console Redirection
Event Logging
Hardware Monitor
Table 21 lists the options available through the I/O Device Configuration submenu. This
submenu configures the I/O ports on the board.
Table 21: I/O Device Configuration Submenu
Feature
Serial port A
Base I/O Address
(This feature is present
only when Serial Port A is
set to enabled)
Interrupt
(This feature is present
only when Serial Port A is
set to enabled)
Serial port B
Base I/O Address
(This feature is present
only when Serial Port B
is set to enabled)
Interrupt
(This feature is present
only when Serial Port B
is set to enabled)
Parallel port
57
Revision 1.40
Security Power
Choices
Disabled
Enabled
(default)
3F8 (default)
2F8
3E8
2E8
IRQ3
IRQ4 (default)
Disabled
Enabled
(default)
3F8
2F8 (default)
3E8
2E8
IRQ3 (default)
IRQ4
Disabled
Enabled
(default)
Boot System
Description
Enables or disables serial port A.
Two devices cannot share the same IRQ.
Choosing Disabled makes serial port A unusable.
Sets the base I/O address for serial port A.
Sets the interrupt for serial port A.
Enables or disables onboard serial port 2.
Two devices cannot share the same IRQ.
Choosing Disabled makes serial port B unusable.
Sets the base I/O address for serial port B.
Sets the interrupt for serial port B.
Enables or disables the onboard parallel port.
Two devices cannot share the same IRQ. Also,
choosing Disabled makes the parallel port
unusable.
Auto is the recommended setting.
System BIOS
