Removing the Chassis Cover

1. Shut down the computer and turn off all external devices. If you do not have a grounding strap,
leave the computer plugged into the wall socket. Leaving the computer plugged in ensures a
positive ground. Disconnect everything but the power cord.
2. Remove the four thumb screws from the rear of the computer.
3. Push the cover back and away from the machine chassis. Lift the cover up and remove from the
chassis.
Figure 1: Removing the chassis cover

Installing the Chassis Cover

1. With the computer upright, place the cover over the chassis. Push the cover towards the front of the
chassis. The front lip of the cover will engage the chassis frame.
2. Replace the four thumb screws from the rear of the computer.
3. Reconnect the cables to the machine.
6
Chassis Cover Removal/Installation
Chassis Cover Removal/Installation
thumb screws
