4.5.6 PCI/PNP Resource Management

CMOS Setup Utility - Copyright (C) 1985-2004,American Megatrends,Inc.
Advanced PCI/Pnp Settings
WARNING:Setting wrong values in
cause system to malfunction.
Clear NVRAM
Plug & Play O/S
PCI Latency Timer
Allocate IRQ to PCI VGA
Palette Snooping
PCI IDE BusMaster
OffBoard PCI/ISA IDE Card
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
.....
→←
:Move Enter:Select
↑ ↓
F7: Previous Values
・ Clear NVRAM
This item for clearing NVRAM during system boot.
・ Plug & Play O/S
This item lets the BIOS configure all the devices in the system or lets the operating
system configure plug and play (PnP) devices not required for boot if your system has
a Plug and Play operating system.
・ PCI Latency Time
This item sets value in units of PCI clocks for PCI device latency timer register.
・ Allocate IRQ to PCI VGA
This item assigns IRQ to PCI VGA card if card requests IRQ or doesn't assign IRQ to
PCI VGA card even if card requests an IRQ.
・ Palette Snooping
This item informs the PCI devices that an ISA graphics device is installed in the system
so the card will function correctly.
・ PCI IDE BusMaster
This item uses PCI busmastering for BIOS reading / writing to IDE derives.
・ OffBoard PCI/ISA IDE Card
This item works for most PCI IDE cards, some PCI IDE cards may require this to be set
to the PCI slot number that is holding the card.
PCI/PNP Resource Management
below sections may
[No]
No
[No]
[64]
[Yes]
[Disabled]
[Enabled]
[Auto]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
.....
+/-/:Value F10:Save
F8: Fail-Safe Defaults
- 2 -
User's Manual
Item Help
Clear NVRAM during
System Boot.
ESC:Exit F1:General Help
F9: Optimized Defaults
