G31 Series
1.2 Specifications-1 (for JW-IG31-MX)
CPU
Main Chipset
Graphics
Main Memory
BIOS
I/O Chipset
Integrated Ports
Sound
Onboard LAN
Expansion Slots
Form Factor
- LGA775 socket for Intel ® Core™2 Extreme/ Core™2 Quad/ Core™
2 Duo/ Pentium ® Dual Core/ Pentium ® D/Pentium ® 4 (800MHz
FSB)/ Celeron ® (Conroe-L) Processors
- FSB 1333MHZ/1066MHz/800MHz/
- Hyper Threading Technology
- Based on G31 + ICH7
- ICH7: Intel FW82801GB
- Intel Graphics Media Accelerator 3100
- 2 x 240-pin DIMM slots support
- Maximum memory capacity up to 4GB
- Supports Dual Channel DDRII 667/800MHz
- Supports Plug&Play
- Supports BIOS ROM Write Protect
- Supports Advanced Power Management ACPI,STR (S3 Optional)
- Supports 1x SYS FAN, 1x CPU FAN
- CPU temperature, Fan speed, System Voltage monitoring
- Onboard Winbond W83627
- 1 x PS/2 Keyboard port
- 1 x PS/2 Mouse port
- 1 x VGA port
- 1 x Debug LED (Optional)
- 1 x SPDIF IN, 1 x SPDIF Out port (Optional)
- 1 x RJ45 port
- 8 x USB 2.0 ports, USB 1.1 is compliant
- 1 x eSATA port
- 1 x IR port (optional)
- 4 x SATA ports by ICH7 , Maximum Speed to 3GB/s
- 1 x IDE connector, 2 x IDE devices could be connected,
Supports ATA 66/100
- 1 x Floppy Drive, supports 360K/720K/1.2M/1.44M/2.88M floppy disk
- Onboard ALC883 Chipset
- Supports 6/8 channel HD Audio,24 bit Audio Codec
- Positioning Audio Support A3D, I3DL2
- Front Panel Jumper, provides stereo MIC port on front panel
- Onboard Marwell 88E8056
- 1 x PCI Express x16 slot
- 2 x PCI slots
- Support PCI Bus interface v2.2 compliant
- Mirco ATX (208*243.8 mm)
-  -
User's Manual
