G31 Series
PCI Express Configuration
Click <Press Enter> key to enter its submenu, it will be display PCI express configuration,
this item sets the active state for express PCI between disabled and enabled.
Smbios Configuration
Click <Press Enter> key to enter its submenu, it will be dispay Smbios configuration, this
item sets SMBIOS Smi support for PnP function within the optional, between enabled
and disabled.
USB Configuration
Click <Press Enter> key to enter its submenu, it will be display USB configuration, this item
allows you to select USB function within the environment.

4.5.5 Advanced Chipset Features

CMOS Setup Utility - Copyright (C) 1985-2004,American Megatrends,Inc.
Advanced Chipset Settings
WARNING:Setting wrong values
may cause system to
► North Bridge Configuration
► South Bridge Configuration
► Colorful Magic Control
→←
:Move Enter:Select
F7: Previous Values
North Bridge Configuration
Click <Press Enter> key to enter its submenu, it will be display north bridge
chipset configuration, this item sets the memory remap feature, DRAM frequency,
DRAM timing by SPD, memory hole, initate graphic adapter, internal graphics mode
select and PEG port selection.
South Bridge Configuration
Click <Press Enter> key to enter its submenu, it will be dispay south bridge
chipset configuration, this item sets USB functions, audio controller, PCIE ports
selection.
Colorful Magic Control
Click <Press Enter> key to enter its submenu, it will be display voltage configuration and
clock configuration, the CPUvore and Memoryvcore will automatic on the screen, also,
the CPU Voltage and Memory voltage can be set according to your selection; the clock
configuration sets the PCIE LAN, BIOS write protect function.
Advanced Chipset Features
in below sections
malfunction.
[Press
Press Enter
Enter]
[Press Enter]
[Press Enter]
+/-/:Value
F10:Save
F8: Fail-Safe Defaults
- 2 -
User's Manual
Item Help
Configure North Bridge
features.
ESC:Exit
F1:General Help
F9: Optimized Defaults
