4.5.4 Advanced BIOS Features

CMOS Setup Utility - Copyright (C) 1985-2004,American Megatrends, Inc.
Advanced Settings
WARNING:Setting wrong values
may cause system to
► CPU Configuration
► IDE Configuration
► Froppy Configuration
► SuperIO Configuration
► Hardware Health Configure
► MPS Configure
► PCI Express Configuration
► Smbios Configuration
► USB Configuration
→←
:Move Enter:Select
↑ ↓
F7: Previous Values
►
CPU Configuration
Click <Press Enter> key to enter its submenu, it will be display configureted CPU
information, including Module Version, Manufacturer , CPU type, Frequency, FSB
Speed, Cache L1 , Cache L2 and so on.
►
IDE Configuration
Click <Press Enter> key to enter its submenu, it will be display IDE configuration, also
you can set the ATA/IDE, SATA function from the options and set the IDE boot order,
or set it as IDE Master, Slave within them.
►
Floppy Configuration
Click <Press Enter> key to enter its submenu, it will be display floppy configuration, and
this item sets the type of floppy drives installed.
►
SuperIO Configuration
Click <Press Enter> key to enter its submenu, it will be display super IO configuration,
and this item sets the function for onboard floppy controller, serial port address,
parallel address, keybaord wakeup and mouse wakeup.
►
Hardware Health Configure
Click <Press Enter> key to enter its submenu, it will be display hardware health
configuration, including System temperature, CPU temperature, FAN speed and all kinds
of voltages.
►
MPS Configuration
Click <Press Enter> key to enter its submenu, it will be display MPS configuration, this item
specfies which version of MPS (Multi-Processor Specification) this mainboard will use. Leave
this item at its default setting.
Advanced BIOS Features
in below sections
malfunction.
Press Enter
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
[Press Enter]
+/-/:Value F10:Save
F8: Fail-Safe Defaults
- 22 -
User's Manual
Item Help
Configuration CPU.
ESC:Exit F1:General Help
F9: Optimized Defaults
