- Page 1 JW-D525M-GT User’s Manual Rev: 1.0, May, 2011...
- Page 2 Disclaimer The intellectual property of this manual belongs to our company. The ownership of all of the products, including accessories and software etc. belong to our company. No one is permitted to copy, change, or translate without our written permission. We compiled this manual based on our careful attitude, but we can not guarantee the accuracy of the contents.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction ..................... 3 1.1 Package Checklist ....................3 1.2 Specifications ......................4 1.3 Mainboard Layout ....................5 1.4 Connecting Rear Panel I/O Devices .................6 Chapter 2 Hardware Setup ..................7 2.1 Choosing a Computer Chassis .................7 2.2 Installing the Mainboard ..................7 2.3 Installation of Memory Modules ................8 2.4 Connecting Peripheral Devices ................9 2.4.1 Serial ATA Connectors .................. -
Page 4: Chapter 1 Introduction
JW-D525M-GT User's Manual Chapter 1 Introduction 1.1 Package Checklist Thank you for choosing our product. Please check the following accessories, if there is any broken or part missing. please contact with your franchiser. • SATA cables • I/O Shield • User's manual •... -
Page 5: Specifications
JW-D525M-GT User's Manual 1.2 Specifications - Intel Pineview Processor - Built-in latest Intel 45nm Dual-Core 525 processor Main Chipset - Tigerpoint(NM10) Integrated Graphics - Integrated Intel Graphics Media Accelerator 3150 - Dual Channel DDR3 800MHz support Main Memory - Max capacity: 4GB DDR3... -
Page 6: Mainboard Layout
JW-D525M-GT User's Manual 1.3 Mainboard Layout (This picture is only for reference) - -... -
Page 7: Connecting Rear Panel I/O Devices
JW-D525M-GT User's Manual 1.4 Connecting Rear Panel I/O Devices The rear I/O part of this mainboard provides the following I/O ports: (This picture is only for reference) • PS/2 Mouse: Connects to a PS/2 mouse. • PS/2 Keyboard: Connects to a PS/2 keyboard. -
Page 8: Chapter 2 Hardware Setup
JW-D525M-GT User's Manual Chapter 2 Hardware Setup 2.1 Choosing a Computer Chassis • Choose a chassis big enough to install this mainboard. • As some features for this mainboard are implemented by cabling connectors on the mainboard to indicators and switches or buttons on the chassis, make sure your chassis supports all the features required. -
Page 9: Installation Of Memory Modules
JW-D525M-GT User's Manual 2.3 Installation of Memory Modules This mainboard provides two 1.5v DDR3 DIMM slots, which supports dual channel memory technology. To activate the dual channel configuration, you need to install two identical (same brand, speed, size and chip-type) memory modules into these DIMM slots. Otherwise the memory will only operate at single channel mode. -
Page 10: Connecting Peripheral Devices
JW-D525M-GT User's Manual 2.4 Connecting Peripheral Devices 2.4.1 Serial ATA Connectors Each SATA connector serves as one single channel to connect one SATA device by SATA cable. 2.4.2 PCI and PCI Express slots Install PCI Express X16 graphics card into slot “PCIE1”. -
Page 11: Chapter 3 Jumpers & Headers Setup
JW-D525M-GT User's Manual Chapter 3 Jumpers & Headers Setup 3.1 Checking Jumper Settings • For a 2-pin jumper, plug the jumper cap on both pins will make it CLOSE (SHORT). Remove the jumper cap, or plug it on either pin (reserved for future use) will leave it at OPEN position. -
Page 12: Fan Power Connectors
JW-D525M-GT User's Manual 3.4 FAN Power Connectors These connectors each provide power to the cooling fans installed in your system. CFAN: CPU Fan Power Connector SFAN1: System Fan Power Connector SFAN1 CFAN or CFAN1 SFAN2 These fan connectors are not jumpers. DO NOT place jumper caps on these connectors. -
Page 13: Additional Usb Port Headers
JW-D525M-GT User's Manual 3.6 Additional USB Port Headers The headers conform to USB 2.0/1.1 specification. Each USB header can provide two USB ports via an optional USB bracket. Pin Assignment Pin Assignment Data 0- Data 0- Data 0+ Data 0+... -
Page 14: S/Pdif Output Connection Header (Optional)
JW-D525M-GT User's Manual 3.8 S/PDIF Output Connection Header (Optional) S/PDIF (Sony/Philips Digital Interface) is a standard audio transfer file format. It is usually found on digital audio equipment such as a DAT (Digital Audio Tape) machine or audio processing device. It allows the transfer of audio from one file to another without the conversion to and from an analog format, which could degrade the signal quality. -
Page 15: Chapter 4 Bios Setup Utility
JW-D525M-GT User's Manual Chapter 4 BIOS Setup Utility BIOS stands for Basic Input and Output System. It was once called ROM BIOS when it was stored in a Read-Only Memory (ROM) chip. Now manufacturers would like to store BIOS in EEPROM which means Electrically Erasable Programmable Memory. -
Page 16: Bios Setup - Cmos Setup Utility
JW-D525M-GT User's Manual 4.5 BIOS Setup — CMOS Setup Utility • In order to increase system stability and performance, our engineering staff is constantly improving the BIOS menu. The BIOS setup screens and descriptions illustrated in this manual are for your reference only, and may not completely match with what you see on your screen. -
Page 17: Main Setting
JW-D525M-GT User's Manual 4.5.3 Main Setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit System Overview ► System Overview System Time [16:23:32] System Date [Fri 03/18/2011] ← Select Screen Power On Beep [Enabled] Select Item ↑ ↓ Enter Go to Sub Screen General Help ►... - Page 18 JW-D525M-GT User's Manual ► SATA1/2 This item sets the status of auto detection of SATA/IDE devices while enterting setup, and BIOS will auto detects the presence of SATA/IDE devices. Press "Enter" Key to enter the submenu. BIOS SETUP UTILITY Main...
-
Page 19: Advanced Setting
JW-D525M-GT User's Manual 4.5.4 Advanced Setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit Advanced Settings Configure CPU. WARNING: Setting wrong values in below sections may cause system to malfunction. ► CPU Configuration ► Onboard Device ← Select Screen ►... - Page 20 JW-D525M-GT User's Manual ► Onboard Device Configuration Click <Enter> key to enter its submenu. BIOS SETUP UTILITY Advanced Onboard Device Configuration Options USB Functions [Enabled] Disabled USB 2.0 Controller [Enabled] Enabled HDA Controller [Enabled] Onboard Lan [Enabled] LAN BootRom [Disabled]...
- Page 21 JW-D525M-GT User's Manual BIOS SETUP UTILITY Advanced Advanced Chipset Settings Select which graphics controller to use as WARNING: Setting wrong values in below sections the primary boot may cause system to malfunction. device. Initate Graphic Adapter [PCI/PEG] ← Select Screen...
- Page 22 JW-D525M-GT User's Manual • Clear NVRAM This item for clearing NVRAM during system boot. • Plug & Play O/S This item lets the BIOS configure all the devices in the system or lets the operating system configure plug and play (PnP) devices not required for boot if your system has a Plug and Play operating system.
-
Page 23: Boot Setting
JW-D525M-GT User's Manual 4.5.5 Boot Setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit Boot Settings Configure Settings during System Boot. ► Boot Settings Configuration ← Select Screen ► Boot Device Priority Select Item ↑ ↓ ► Hard Disk Drives ►... -
Page 24: Security Setting
JW-D525M-GT User's Manual 4.5.6 Security Setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit Security Settings Install or Change the password. Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password ← Select Screen User Access Level... -
Page 25: Power Setting
JW-D525M-GT User's Manual 4.5.7 Power Setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit Power Settings Select the ACPI state used for System Suspend. Suspend mode [S1 (POS)] ← Select Screen Select Item ↑ ↓ Enter Go to Sub Screen... -
Page 26: Exit Setting
JW-D525M-GT User's Manual 4.5.9 Exit setting BIOS SETUP UTILITY Main Advanced Boot Security Power PC&Health Exit Exit Options Exit system setup after saving the Save Changes and Exit changes. Discard Changes and Exit Discard Changes F10 key can be used for this operation. -
Page 27: Chapter 5 Driver Installation
JW-D525M-GT User's Manual Chapter 5 Driver Installation Check your package and there is Driver CD included. This CD consists of all drivers you need. In addition, this CD also include an auto detect software which can tell you which hardware is installed, and which drivers needed so that your system can function properly. - Page 28 JW-D525M-GT User's Manual When you choose Mainboard Driver installation Utility, the drivers menu should appear as below: Back <- INTEL Chipset Installation Utility INTEL Chipset VGA Graphics Driver Onboard LAN Driver Realtek HD Audio Driver Exit (This picture is only for reference)
