Table 2: FortiGate-5001C LEDs (Continued)
LED State
Green
Base 1 and 2
Flashing
Green
Off
OOS
Amber
(Out of Service)
PWR (Power) Green
Off
Flashing
STA (Status)
Green
Off or
Flashing
green
ACC (Disk
activity)
Green
1 and 2 Flashing
Green
Off
Link/Act Solid
(Left Green
LED)
Blinking
MGMT 1
Green
and
Off
MGMT 2
Speed Green
(Right
Amber
LED)
Off
Description
Base backplane interface 1 or 2 (base1 or base2) is
connected at 1 Gbps.
Network activity at base backplane interface 1 or 2
(base1 or base2).
Normal operation.
A fault condition exists and the FortiGate-5001C blade
is out of service (OOS). This LED may also flash very
briefly during normal startup.
The FortiGate-5001C board is powered on.
The FortiGate-5001C board is powered on.
The FortiGate-5001C is starting up. If this LED is
flashing at any time other than system startup, a fault
condition may exist.
The ACC LED flashes green when the FortiGate-5001C
board accesses the FortiOS flash disk. The FortiOS
flash disk stores the current FortiOS firmware build and
configuration files. The system accesses the flash disk
when starting up, during a firmware upgrade, or when
an administrator is using the CLI or GUI to change the
FortiOS configuration. Under normal operating
conditions this LED flashes occasionally, but is mostly
off.
The correct cable is connected to the port1 or port2
interface and the connected equipment has power.
Network activity at the interface.
No link is established.
Indicates the management interface (mgmt1 or mgmt2)
is connected with the correct cable and the attached
network device has power.
Indicates network traffic on this interface.
No Link
Connection at 1 Gbps.
Connection at 100 Mbps.
Connection at 10 Mbps.
