Factory default settings

Factory default settings

Configuring NAT/Route mode

26
The FortiGate-5001C unit ships with a factory default configuration. The default
configuration allows you to connect to and use the FortiGate-5001C web-based manager
to configure the FortiGate-5001C board onto the network. To configure the
FortiGate-5001C board onto the network you add an administrator password, change the
network interface IP addresses, add DNS server IP addresses, and, if required, configure
basic routing.
Table 6: FortiGate-5001C factory default settings
Operation Mode
Administrator Account
mgmt1 IP/Netmask
mgmt2 IP/Netmask
Default route
Primary DNS Server:
Secondary DNS Server:
At any time during the configuration process, if you run into problems, you can reset the
FortiGate-5001C board to the factory defaults and start over. From the CLI enter
execute factory reset.
Use Table 7 to gather the information you need to customize NAT/Route mode settings
for the FortiGate-5001C security system. You can use one table for each board to
configure.
Table 7: FortiGate-5001C board NAT/Route mode settings
Admin Administrator Password:
IP:
mgmt1
Netmask:
IP:
port1
Netmask:
IP:
port2
Netmask:
Device (Name of the Interface
connected to the external
network):
Default Gateway IP address:
Default Route
The default route consists of the name of the interface connected
to an external network (usually the Internet) and the default gateway
IP address. The default route directs all non-local traffic to this
interface and to the external network.
Primary DNS Server:
DNS Servers
Secondary DNS Server:
NAT/Route
User Name: admin
Password: (none)
192.168.1.99/24
192.168.100.99/24
Gateway: 192.168.100.1
Device: mgmt2
208.91.112.53
208.91.112.52
FortiGate-5001C Security System Guide
Quick Configuration Guide
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
_____._____._____._____
