FortiGate-5001C mounting components

FortiGate-5001C mounting components
14
• An electrostatic discharge (ESD) preventive wrist strap with connection cord
FortiGate-5001C boards must be protected from static discharge and physical shock.
Only handle or work with FortiGate-5001C boards at a static-free workstation. Always
wear a grounded electrostatic discharge (ESD) preventive wrist strap when handling
FortiGate-5001C boards.
1 Attach the ESD wrist strap to your wrist and to an available ESD socket or wrist strap
terminal.
2 If you have installed the FortiGate-5001C board in a chassis, remove it.
For removal instructions, see
on page 17.
3 Use Figure 3 on page 12
4 If required, change SW2 to the correct setting.
5 Insert the FortiGate-5001C board into a chassis and verify that the board starts up
and operates correctly.
For inserting instructions, see
To install a FortiGate-5001C board you slide the board into an open slot in the front of an
ATCA chassis and then use the mounting components to lock the board into place in the
slot. When locked into place and positioned correctly the board front panel is flush with
the chassis front panel. The board is also connected to the chassis backplane.
FortiGate-5001C boards are horizontal when inserted into a FortiGate-5060 chassis and
vertical when inserted into a FortiGate-5140 chassis. The inserting and removing
procedures are the same in either case. For clarity the descriptions in this document
refer to the left (top) and right (bottom) mounting components.
To position the board correctly you must use the mounting components shown in
Figure 6 for the right (bottom) side of the front panel. The mounting components on the
left (top) side of the FortiGate-5001C front panel are the same but reversed. The
FortiGate-5001C mounting components align the board in the chassis slot and are used
to insert and eject the board from the slot.
"Shutting down and removing a FortiGate-5001C board"
to locate SW2 on the FortiGate-5001C board.
"Inserting a FortiGate-5001C board" on page
Hardware installation
15.
