FUNCTION SELECTOR SWITCH
OFF Off position
V DC and AC voltages up to 600V, with high impedance: 10MΩ
Velec AC voltages up to 600V, with low impedance: 270kΩ
Note: Also available on DC voltage.
Hz (C.A 5220 only)
Frequencies of voltages, up to 200kHz
Ω Ω Ω Ω Ω Continuity sound test for a resistance R ≤ 40Ω, and
resistance measurements up to 40MΩ
Note: The continuity test
when the instrument is switched on.
Diode test. Measurement of the voltage of the junction in
forward direction
Capacitances up to 40µF
A (C.A 5220 only)
10A
mA (C.A 5220 only)
Current ranges up to 400mA
TERMINALS
Ø 4mm safety terminals
COM : common, black
+ : red
10A (C.A 5220 only) : red lead for the 10A
Connect the leads to the multimeter and connect it in parallel to the
circuit to be tested.
Place the selector switch on voltmeter (V) function (high
impedance). The instrument is in AC mode. Press the AC/DC button
to select DC and vice versa.
Automatic range selection: read the measured value.
Freeze the value, by pressing the HOLD button.
C.A 5220 only
If necessary, press the following buttons:
RANGE to select the ranges manually
MIN/MAX to read the min or max values
to switch on the backlight of the display
current ranges (via the 10A terminal)
AC/DC
3 - DC AND AC VOLTAGE
is selected automatically
(via the + terminal)
AC/DC
5
ranges
AC/DC
