Always switch Off the circuit to be tested before
connecting the multimeter to the circuit
Warning: connect the leads to the multimeter and connect in
series to the circuit
- the red lead to the + terminal up to 400mA
- the red lead to the 10A terminal, from 400mA to 10A
Place the selector on the A or mA ammeter function
Press the AC/DC button to select AC or DC
Energize the circuit to be tested
Automatic range selection : read the measured value
If necessary, press the following buttons
- RANGE to manually select the ranges
- MIN-MAX to read the min or max values
- to light the display
DC currents
A DC
Voltage
drop
(2)
Digital
resolution
Bargraph
resolution
Accuracy
Protection
(3)
AC currents
A AC
Voltage
drop
(2)
Digital
resolution
Bargraph
resolution
Accuracy
(4)
Protection
(3)
(1) 4000 count display limited to 10A Between 5A and 10A, to avoid overheating,
limit the operating time to 10 minutes
(2) Voltage drop at the terminals for 40mA, 400mA, 10 A
(3) Permitted overloads :
600mA for 30 seconds for the 400mA range
15A for 30 seconds for the 10A range
(4) Use on frequency : 40Hz to 500Hz
9 - DC and AC CURRENT
(C.A 5220 only)
40mA
600mV
10µA
1mA
± 1.5% of Reading ±1ct
Fuse 0.4A HBC
40mA
600mV
10µA
1mA
± 1.5% of Reading ±1ct
Fuse 0.4A HBC
400mA
4.5V
100µA
10mA
400mA
4.5V
100µA
10mA
9
10A
(1)
600mV
10mA
1A
± 1.5% of
Reading ±2cts
Fuse 12A HBC
10A
(1)
600mV
10mA
1A
± 2% Reading
± 2cts
Fuse 12A HBC
