Comtech EF Data MBT-4000 Installation And Operation Manual page 62

MBT-4000 Multi-Band Transceiver System
Remote Control
Command Valid on
Parameter (Instruction
Type Code and BDC, or
qualifier)
Retrieve N/A All
Configuration
Status
Redundancy RED=x MBT
State
Arguments
MBT, for Command
(Note that all arguments are ASCII numeric codes – i.e.,
or Response
BUC to Query
65 bytes Query only.
(MBT-4000) Used to Query the configuration status of the unit
98 bytes
(BDC), Example for MBT-4000 base:
76 bytes <0001/RCS?{cr}
(BUC) >0001/RCS={cr}
alphanumeric BF1=X {cr}
BF2=X {cr}
BT1=DN{cr}
BT2=UP{cr}
RED=0{cr}
RAM=00{cr}
MBT=N, A, or B
EXT=0{cr}{lf}
Example for BDC or BUC:
<0001A1/RCS?{cr}
>0001A1/RCS={cr}
FLO=06300{cr}
ATT=01.00{cr}
MUT=1{cr}
SLP=0.3{cr}
LCS=0{cr}
LCW=99{cr}
LFL=1{cr}
REF=XXXX{cr} (reserved for future use)
XRE=X{cr} (reserved for future use)
AFR=0{cr}{lf}
Note: For BUC, LCS, LCW, & LFL will not be shown.
1 byte, Command or Query.
value of 0,1, Controls redundancy state, where:
or 2 0=Off
1=Enables redundancy using single base unit
2=Enables redundancy using dual base units
Example: RED=1
Description of Arguments
ASCII codes between 48 and 57)
A–18
Revision 4
MN/MBT4000.IOM
Response to Query
Command (Instruction
(Target to Code and
Controller) qualifier)
N/A RCS?
RED= (message OK) RED?
RED? (received OK,
but invalid arguments
found)
RED* (message OK,
but not permitted in
current mode)
Response to
Query
(Target to
Controller)
RCS=x....x
(see description
for details of
arguments)
RED=x
(same format as
command
arguments)
