MBT-4000 Multi-Band Transceiver System
Remote Control
Command Valid on
Parameter (Instruction
Type Code and BDC, or
qualifier)
Concise Alarm N/A All
Status
Arguments
MBT, for Command
(Note that all arguments are ASCII numeric codes – i.e.,
or Response
BUC to Query
20 bytes, Query only.
numeric Used to query the alarm status of the unit.
Example: <0001/CAS?{cr}
Where:
a through l = 0 or 1, 0=OK, 1=FLT
All:
a=+15V Power Supply
b=+7.5V Power Supply
c=+5.0V Power Supply
MBT-4000:
d=+28V Power Supply
e=Ref Oscillator Lock Detect
f=Intermodule Communications
g=Max current on LNA power supply AUX COMM1
h=Max current on LNA power supply AUX COMM2
i=Current window LNA power supply AUX COMM1
j=Current window LNA power supply AUX COMM2
k=Fault input AUX COMM1 (Pin F, J9)
l=Fault input AUX COMM2 (Pin F, J8)
BDC/BUC:
d=X (reserved for future use)
e=Synthesizer Lock Detect
f=Heat-sink Temperature
g=LNA current (BDC only, reserved on BUC)
h=Reserved, always zero
i-l=Not sent.
Description of Arguments
ASCII codes between 48 and 57)
>0001/CAS=abcdefghijkl{cr}{lf}
A–8
Revision 4
MN/MBT4000.IOM
Response to Query
Command (Instruction
(Target to Code and
Controller) qualifier)
N/A CAS?
Response to
Query
(Target to
Controller)
CAS=x...X
(see description
for details of
arguments)
