Transceiver System Controls and Functions
- Transceiver Front Panel
MICROPHONE JACK
FRONT SPEAKER
Microphone Jack
CONTROL UNIT
- Transceiver Rear Panel
POWER 12/24 V DC
8
TCBR2000 man_reized.indd 8
1) Microphone Jack
Insert the microphone into this jack. Use the guide for easy
connection.
2) Front Speaker
The front speaker makes the audio always loud enough even
when the transceiver is located in the audio compartment
(center fascia) or in some places difficult to be found.
3) Microphone Jack(Handsfree)
Insert the handsfree microphone into this jack.
4) AUX Jack
AUX JACK
Connect an AUX connector of your audio equipment such as
your MP player into this jack.
5) Remote Control Unit Jack
Install the remote control unit connector into this jack.
6) Remote LCD Unit Jack
LCD UNIT
Install the remote LCD unit connector into this jack.
7) Power 12V/24 DC
Connect the power supply cable to this port.
NOTE : This transceiver works properly at 1.V DC input.
And one high voltage protection circuit is installed to pro-
tect this transceiver
from 4V DC connection.
LCD UNIT
8) Remote LCD Unit Jack
Install the Remote LCD unit connector into this jack.
English
TCB-R2000
2011.3.14 5:34:20 PM
