Summary of Contents for TTI TCB-660
-
Page 1: Instruction Manual
4W MOBILE CB TRANSCEIVER INSTRUCTION MANUAL www.ttikorea.co.kr... -
Page 2: Table Of Contents
CONTENTS Introduction Supplied Accessories Installation Transceiver Controls and Functions Microphone Jack LCD Display Down Button Up Button AM/FM and LCR Button Scan and Lcok Button Emergency and Calling Button Squelch Control Knob Volume and Power On/Off Knob Antenna Connector Power 13.2DC EXT-SPK Jack LCD Display Microphone... -
Page 3: Introduction
The transceiver should normally be mounted horizontally, but may be mounted vertically. The bracket supplied can be fitted above or below the case allowing the TCB-660 to be cradled by the bracket or suspended from it. TCB-660... - Page 4 Connect the power cable to the transceiver cable. Mount the microphone bracket on one side of the transceiver, or near it using two screws included. Connect the microphone to the transceiver’s microphone receptacle. Now you are ready operate transceiver. TCB-660...
- Page 5 Make sure that you have a solid metal-to-metal ground connection. Be careful not to damage the cable during the installation. Warning : Never try the operation of your transceiver before connecting a proper antenna in order not to cause any damage. TCB-660...
-
Page 6: Transceiver Controls And Functions
2) LCD Display Most operational information is displayed. Please see item no. 5 for the details of information. 3) Down Button Press this button briefly to select the channel one by one that you like to use. TCB-660... -
Page 7: Up Button
If you press the PTT button during scanning, the radio will return to your original channel. Scanning will resume after the scan receive time and/or the scan delay time. Use the channel selector or quick up/quick down selector to resume scanning immediately. TCB-660... -
Page 8: Emergency And Calling Button
Insert the mail connector of the antenna cable into this female antenna connector. 11) Power 13.2 DC Connect the power supply cable to this port. 12) EXT-SPK Jack Connecting a loud speaker to this port makes the built-in speaker turned off. TCB-660... -
Page 9: Lcd Display
Also, this lock works same as the lock button on the transceiver front panel. PTT Button : While pressing this button, you can transmit. Microphone Connector Connect this to the microphone jack on the front panel of the transceiver. TCB-660... -
Page 10: Menu Setting Mode
Or the selections and changes will be automatically confirmed after 5 seconds of the selections and changes. Using Scan button to return to the previous main menu features will be accompanied by the automatic confirmation of the selected values and changes. TCB-660... -
Page 11: How To Operate The Transceiver
This transceiver has "EC" band setting when it is shipped out from the factory. Settings Display Band Europe 40 Ch FM 4W Spain 40 Ch AM/FM 4W France 40 Ch FM 4W, 40 Ch AM 1W TCB-660... -
Page 12: Trouble Shooting
Europe 40 Ch FM 4W, 40 Ch AM 1W 10. Trouble Shooting If you experience problems with your TCB-660 transceiver, first check the power supply source. Poor connection of the power supply source can cause problems such as no transmission, no reception or poor reception, and weak or no sound. -
Page 13: Ce Declaration
11. CE Declaration CE versions of the TCB-660 which display the CE symbol on the product label, comply with the essential requirements of the European Radio Telecommunication Terminal Directive 1999/5/CE. This warning symbol indicates that this equipment operates in non-harmonised frequency bands and/or may be subject to licensing conditions in the country of use. -
Page 14: Specification
60 dB Adjacent Channel Rejection 60 dB Conducted Spurious More than 60 dB Frequency Response 300 to 2500Hz Built-in Speaker 8 Ohms, round Squelch Adjustable; Threshold less than 1 microvolt * Specification is subject to change without prior notice. TCB-660... -
Page 15: Restrictions On The Use
40 Ch - 1W AM - Individual licence is required 40 Ch - 4W FM - Individual licence is required UK-RA-MPT 1382/MPT1320; UK-R&TTE - S.IL. 2000:730 POLAND PL EU 40 Ch - 4W FM / AM - Free use TCB-660... -
Page 16: Frequency Table
27.365 27.365 27.365 27.365 27.360 27.95125 27.375 27.375 27.375 27.375 26.925 27.375 27.370 27.96125 27.385 27.385 27.385 27.385 27.385 27.380 27.97125 26.935 27.395 27.395 27.395 27.395 26.945 27.395 27.390 27.98125 27.405 27.405 27.405 27.405 26.955 27.405 27.400 27.99125 AM/FM TCB-660... - Page 17 DECLARATION OF CONFORMITY We, TTI Tech Co.,Ltd (TTI house, 163-4, Poi-dong, Gangnam-gu, Seoul, Korea) declare on our sole responsibility that this equipment complies with the essential requirements of the Radio and Telecommunications Terminal Equipment Directive, 1999/5/EC, and that any applicable Essential Test Suite measurements have been performed.
