Summary of Contents for TTI TCB-900
- Page 1 4W MOBILE CB TRANSCEIVER TCB-900 I N S T R U C T I O N M A N U A L www.ttikorea.co.kr...
- Page 2 Our Thanks to You Our Thanks to You Thank you for purchasing a TTI CB TRANSCEIVER radio. Properly used, this TTI product will give you many years of reli- able service. All our products are built to offer excellent value by combining advanced features, great design and manufacturing quality.
-
Page 3: Table Of Contents
7. How to Operate the Transceiver ........14 8. Trouble Shooting ............14 9. CE Declaration ..............14 10. Safety Requirement ............15 11. Specification ..............16 12. Restrictions on the use ........... 17 13. Declaration of Conformity ..........18 TCB-900 English 3... -
Page 4: Introduction
The transceiver should normally be mounted horizontally, but may be mounted vertically. The bracket supplied can be fitted above or below the case allowing the TCB-900 to be cradled by the bracket or suspended from it. - Page 5 (5) Mount the microphone bracket on one side of the transceiver, or near it using two screws included. Connect the microphone to the transceiver’s microphone recep- tacle. Now you are ready to operate the transceiver. TCB-900 English 5...
-
Page 6: Installing An Antenna
(4) Make sure that you have a solid metal-to-metal ground connection. (5) Be careful not to damage the cable during the installation. Warning : Never try the operation of your transceiver before connecting a proper antenna in order not to cause any damage. TCB-900 English... -
Page 7: Transceiver Controls And Functions
Transceiver Controls and Functions 4. Transceiver Controls and Functions Backlight & AM/FM Button TCB-900 English 7... -
Page 8: Front Speaker
Backlighting & AM/FM selection. The colours include blue, purple and amber. Momentarily press this button to change the colour. AM/FM: This button allows user to switch between AM and FM modes by pressing this button for about 2 seconds. TCB-900 English... -
Page 9: Scan
Turn the channel knob while the band information is blinking and press the PTT button or just wait for about 10 seconds for your selection confirmation. This transceiver has "EC" band setting when it is shipped out from the factory. TCB-900 English 9... -
Page 10: Attenuation And Menu(M)
Transceiver Controls and Functions Setting Display Settings Europe 40 Ch. FM 4W Spain 40 Ch. AM/FM 4W France 40 Ch. FM 4W, 40 Ch AM 4W Poland 40 Ch. AM / FM 4W (Polish Frequencies : 5KHz) UK 40 Ch. FM 4W (British Frequencies) UK 40 Ch. - Page 11 (or follow any other instruction given by your headset supplier) the proper key until the LCD of the transceiver displays OK ( 5. The transceiver automatically returns to the stand-by mode and the Bluetooth is active now. TCB-900 English 11...
-
Page 12: Emergency(9/19) And Keypad Lock
Your external speaker will be activated by connecting through this jack. This will make your built-in speaker turned off(The external speaker is not supplied). Power 13.2V DC 14) Power 13.2V DC Connect your power supply cable to this power connec- tor. TCB-900 English... -
Page 13: Lcd Display
PTT Button : While pressing this button, you can transmit. 6 Pin Microphone Connector : Connect this to the microphone jack on the front panel of the transceiver. TCB-900 English 13... -
Page 14: How To Operate The Transceiver
9) Release the PTT button to receive. 8. Trouble Shooting If you experience problems with your TCB-900 transceiver, first check the power supply source. Poor connection of the power supply source can cause problems such as no transmission, no reception or poor reception, and weak or no sound. -
Page 15: Safety Requirement
The same colors are present on the battery and in the fuse box of the car. The unit must be wired for the negative ground only. To avoid damage, do not operate your CB radio without connecting a proper antenna. TCB-900 English 15... -
Page 16: Specification
Adjacent Channel Rejection Less than -57 dBm Conducted Spurious 300 to 2500Hz Frequency Response 8 Ohms, round Built-in Speaker Adjustable; Threshold less than 1 microvolt Squelch DSS: Less than 2 microvolt * Specification is subject to change without prior notice. TCB-900 English... -
Page 17: Restrictions On The Use
40 Ch - 4W AM - Individual licence is required 40 Ch - 4W FM - Individual licence is required UK-RA-MPT 1382/MPT1320; UK-R&TTE - S.IL. 2000:730 POLAND 40 Ch - 4W FM / AM - Free use PL EU TCB-900 English 17... -
Page 18: Declaration Of Conformity
Declaration of Conformity 13. Declaration of Conformity We, TTI Tech Co.,Ltd (4F, JuWon Bldg, 1188, Gaepo-dong, Gangnam-gu, Seoul, Korea) declare on our sole responsibility that this equipment complies with the essential requirements of the Radio and Telecommunications Terminal Equipment Directive, 1999/5/EC, and that any applicable Essential Test Suite measure- ments have been performed.
