Installation and Operation Guide
XX259-00-01
V662-D-1 High-Resolution
Analog WDR Camera
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: 631-952-2288
Fax: 631-951-2288 Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8259-00-01
Issued: 513
Copyright © 2013 Vicon Industries Inc. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Vicon V662-D-1
Summary of Contents for Vicon V662-D-1
- Page 1 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
- Page 3 LIMITATION OF LIABILITY THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS; HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES - ii -...
-
Page 4: Explanation Of Graphical Symbols
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMEMT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 5: Ce Compliance Statement
FCC COMPIANCE STATEMENT This equipment has been tested and found FCC INFORMATION: to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 7 PRECAUTIONS Before installation, carefully read the manual to ensure correct operation and setup, heeding all warnings and instructions. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Ensure manual is kept in good condition for future use. Do not install the device near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat.
-
Page 8: Table Of Contents
TABLE OF CONTENTS CONTENTS OF PACKAGE ------------------------------------------------------------------------- 1 INTRODUCTION --------------------------------------------------------------------------------------- 2 CAMERA OVERVIEW -------------------------------------------------------------------------------- 3 CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 4 CONTROL AND CONNECTIONS / DAY&NIGHT I/O TERMINALS----------------------- 14 LENS ----------------------------------------------------------------------------------------------------- 15 SPECIFICATIONS ------------------------------------------------------------------------------------- 16 CONTENTS OF PACKAGE Installation of the camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes. -
Page 9: Introduction
INTRODUCTION The V662-D-1 camera provides high-quality images using Sony 1/3” CCD and digital signal processing LSIs. Features: 1/3" Super-HAD CCD Super High-Resolution (700 TVL) Wide Dynamic Range (~x512) Day & Night (Auto, Manual, External, Filter Delay, Change Level Adjust) ... -
Page 10: Camera Overview
CAMERA OVERVIEW SIDE VIEW TOP VIEW FRONT VIEW Left Button Up Button Enter Button REAR VIEW Right Button Down Button Day/Night External I/O Motion ALARM OUT RS-485/UTP (optional) -
Page 11: Camera Adjustment
<Navigating the Menu System> 1) Menu: Represents the present menu subject on top of screen. When using Multi-Camset, CAM ID and “camset” name included. Common Headers: : Currently active menu item is displayed. Move with Up/Down keys. : There is sub-menu. Press Enter key to go to sub-menu. : Indicates the selected menu item. -
Page 12: Auto Exposure
- R: Adjust red color. - B: Adjust blue color. - Push/Set: Tracking WB of current screen and represent R, B values. - Default: Restore R, B default values. 5) Fix/FL Mode: Fixed color temperature mode (fluorescent lamp environment). 6) Fix/Outdoor Mode: Fixed color temperature (6300 ºK) mode, for outdoor environment. - Page 13 6) Brightness: Adjust AE reference level. <Mask> Up to 10 Privacy Zones can be configured. Because they share area ID with PVA Zones, they cannot use the same ID. 1) Zone: Select mask number. NOTE: *If you see "PVA" in the “Func” menu, PVA function is currently being used in the area. 2) Func: Select mask on/off.
- Page 14 * The abandon/absent detection can be inaccurate. Scene Change: Detect a change in the screen. NOTE: * This is good for detecting scene changes, including vertical lines or high contrast objects of the background. * Do not use this as a signal to start video recording. * The scene change detection can be inaccurate.
- Page 15 counting value/DEC: Decrement counting value). NOTE: * The counting value can be inaccurate. Screen: Printed event at bottom side by side scrolling. Icon Subject Range Motion occurred. Rect, Poly, Motion Line Motion occurred in the area. Rect, Poly Motion Inside Object on outside moves into the area.
- Page 16 area, detecting direction of moving out. Direction *) Don’t use as a signal for starting video recording. *) Not supported in Simple mode. Event will occur the object moves in a Line Move clockwise direction that start around. Clockwise *) Don’t use as a signal for starting video recording.
-
Page 17: System Setup
* Priority: Tracking priority: Zone > Loitering > Abandon/Absent > Obj. * Maximum 4 objects can be represented. * Same priority: Continuing detect. And Obj. > Size - All Object: Tracking all detected objects. - Loitering: Tracking detected loitering object. - Abandon/Absent: Tracking detected absent/abandon area. - Page 18 - Display: Configurations for display camera ID & title. Cam ID: Select camera ID display on/off. Title: Select title display on/off. Display Pos: Change position the string location. - Language: Change menu OSD language. 2) Setup Tools - System Config Multi-Camset: Select On (user can use 4 configuration sets)/Off Video Analytics: Select PVA mode.
- Page 19 NOTE: * If registered points are more than 63 points, print “Memory Full” and stop action. Marker: Use this if user sees other points. Finder: Use this to move finder screen. UnDo: Cancel the registered point. Done: Return to previous menu. Unregist: Deleting registered pixel.
- Page 20 - D/N Threshold: Configure the threshold level for D/N mode to change (Low/Mid/High/User). NOTE: * User Mode: Difference between D>N Level and N>D Level must be more than 2 and D>N must be less than N>D. D>N: Adjust level of changing point of Day -> Night. N>D: Adjust level of changing point of Night ->...
-
Page 21: Control And Connections / Day&Night I/O Terminals
CONTROL AND CONNECTIONS OF TERMINALS UTP- UTP+ D&N D&N ALARM RS-485+ RS-485- (optional) (optional) (RX) (TX) UTP Connections/Video output (optional) ● 1 PIN: UTP- ● 2 PIN: UTP+ DAY&NIGHT I/O Terminals To select Day/Night mode using external equipment, connect control lines to the appropriate terminals. -
Page 22: Lens
LENS The lens is not supplied with this camera. Purchase a lens suitable for your requirements. These cameras accept both C- and CS-mount type lenses. <Notes > *) For using main functions it is recommended to use a DC-type auto iris lens. If the lens is dirty with fingerprints or other marks, the image quality might be poor. -
Page 23: Specifications
SPECIFICATIONS ITEM V662-D-1 V662-D-P-1 V662-D-1-PM Input Voltage Dual (12 VDC, 24 VAC ±10%) 100-240V~50Hz±1Hz Power Consumption 3.5 Watts (300mA) 4.0 Watts(55mA) Power Connector 2-Pin Terminal Block Power Cord VIDEO Image Device 1/3" Sony Super-HAD II PS 960H CCD Total Pixels... - Page 24 MEMO...
-
Page 25: Shipping Instructions
Vicon Industries Inc. 89 Arkay Drive Hauppauge, NY 11788 Phone: 631-952-2288; Toll-Free: 1-800-645-9116; Fax: 631-951-2288 For service or returns from countries in Europe, contact: Vicon Industries (U.K.) Ltd Brunel Way Fareham, PO15 5TX United Kingdom Phone: +44 (0)1489/566300; Fax: +44 (0)1489/566322... -
Page 26: Vicon Standard Equipment Warranty
Vicon Standard Equipment Warranty Vicon Industries Inc. (the “Company”) warrants your equipment to be free from defects in material and workmanship under Normal Use from the date of original retail purchase for a period of three years, with the following exceptions: Monitors, all models: One year from date of original retail purchase. - Page 28 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-2288 800-645-9116 Fax: 631-951-2288 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Vicon Germany Kornstieg 3 D-24537 Neumuenster...
