2.1

Electrostatic Warning

The AT91SAM9263-EK evaluation board Rev. B is shipped in protective anti-static packaging. The
board must not be subjected to high electrostatic potentials. A grounding strap or similar protective
device should be worn when handling the board. Avoid touching the component pins or any other metal-
lic element.
2.2

Requirements

In order to set up the AT91SAM9263-EK evaluation board Rev. B, the following items are needed:
the AT91SAM9263-EK evaluation board Rev. B itself
AC/DC power adapter (12V at 1A), 2.1 mm by 5.5 mm
2.3

Layout

See Figures 2-1 and
AT91SAM9263-EK Evaluation Board Rev. B User Guide

Setting Up the AT91SAM9263-EK Board Rev. B

2-2.
Section 2
2-1
6341B–ATARM–17-Sep-08
