Configuration
Table 4-1. Configuration Jumpers and Straps (Continued)
Designation
R76
R78
R80
R82
R87
R89
R91
R93
R112
R126
R127
R128
TP67
TP68
TP69
TP70
TP71
TP72
TP73
TP74
Note:
4-2
6341B–ATARM–17-Sep-08
Default Setting
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
N.A
N.A
N.A
N.A
N.A
N.A
N.A
N.A
1. These jumpers are provided for power consumption measurement use. By default, they are closed. To
use this feature, the user has to open the strap and insert an ammeter.
Feature
Enables the use of the RS232 COM PORT TXD signal (PA26)
Enables the use of the RS232 COM PORT RTS signal (PA28)
Enables the use of the RS232 COM PORT RXD signal (PA27)
Enables the use of the RS232 COM PORT CTS signal (PA29)
Enables the use of the CAN BUS driver RS control signal (PA26)
Enables the use of the CAN BUS driver CANTXRT RTS signal (PA28)
Enables the use of the RS232 COM PORT RXD signal (PA27)
Enables the use of the RS232 COM PORT CTS signal (PA29)
Enables the use of interrupt ETHERNET PHY (PE31)
Enables the use of TOUCH SCEEN CONTROLLER (PB11_SPI0_NPCS3)
Enables the use of TOUCH SCEEN CONTROLLER BUSY signal (PA31)
Enables the use of TOUCH SCEEN CONTROLLER PENIRQ (PA15_IRQ1)
GND Test point
GND Test point
GND Test point
GND Test point
0 to 3.3V analog user's input
0 to 3.3V analog user's input
AGND of TP71
AGND of TP72
