Setting Up the AT91SAM9263-EK Board Rev. B

2.4

Powering Up the Board

The AT91SAM9263-EK requires 12V DC. DC power is supplied to the board via the 2.1 mm by 5.5 mm

socket J1. Coaxial plug center positive standard.

2.5

The user has the possibility to plug a battery (3V Lithium Battery CR1225 or equivalent) in order to per-

manently power the backup part of the device.

2.6

The AT91SAM9263-EK evaluation board Rev. B is delivered with a CD-ROM that allows the user to

begin evaluation of the AT91 ARM Thumb 32-bit microcontroller quickly. Please refer to the AT91 web

site, http://www.atmel.com/products/AT91/, for the most up-to-date information on getting started with

the AT91SAM9263-EK.

2-4

6341B–ATARM–17-Sep-08

AT91SAM9263-EK Evaluation Board Rev. B User Guide
