  • Page 1 AT91EB40A Evaluation Board ....................User Guide...

  • Page 3: Table Of Contents

    Section 1 Overview....................1-1 Scope ......................1-1 Deliverables ....................1-1 The AT91EB40A Evaluation Board............1-2 Section 2 Setting Up the AT91EB40A Evaluation Board........2-1 Electrostatic Warning ................2-1 Requirements....................2-1 Layout .......................2-1 Jumper Settings ..................2-2 Powering Up the Board ................2-2 Measuring Current Consumption on the AT91R40008 ......2-2 Section 3 The On-board Software ................
  • Page 4 Section 6 Appendix B – Schematics..............6-1 Schematics ....................6-1 Section 7 Appendix C – Bill of Materials............... 7-1 Section 8 Appendix D – Flash Memory Mapping..........8-1 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 5: Overview

    Scope The AT91EB40A Evaluation Board enables real-time code development and evaluation. It supports the AT91R40008. This guide focuses on the AT91EB40A Evaluation Board as an evaluation and demon- stration platform: ! Section 1 provides an overview. ! Section 2 describes how to set up the evaluation board.

  • Page 6: The At91Eb40A Evaluation Board

    ! 2 x 32-pin EBI expansion connectors ! 2 x 32-pin I/O expansion connectors ! 20-pin JTAG interface connector If required, user-defined peripherals can also be added to the board. See Section 5 for details. AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 7 Figure 1-1. AT91EB40A Evaluation Board Block Diagram AT91R40008 Reset Controller 256K Byte Flash SRAM ARM7TDMI Processor JTAG Connector Expansion Connector 66 MHz Clock Crystal Generator AMBA Bridge LEDs Interrupt Push-buttons Controller Timer Expansion Counters Connector Power Supply VDDCORE (1.8V) VDDIO (3.3V)
  • Page 8 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 9: Setting Up The At91Eb40A Evaluation Board

    Avoid touching the compo- nent pins or any other metallic element. Requirements In order to set up the AT91EB40A evaluation board, the following requirements are needed: ! The AT91EB40A evaluation board itself.

  • Page 10: Jumper Settings

    DDCORE ture enables the current consumption of the AT91 product to be measured. Consumption on the See “Power Consumption Measurement Straps (JP5A/B, JP7A/B)” on page 5-3 in Sec- tion 5 for further details. AT91R40008 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 11 Testing the To test the AT91EB40A Evaluation Board, perform the following procedure: AT91EB40A 1. Hold down the SW1 button and power-up the board, or generate a reset and wait Evaluation Board for the light sequence on each LED to complete. All the LEDs light.
  • Page 12 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 13: The On-Board Software

    Section 3 The On-board Software The AT91EB40A The AT91EB40A Evaluation Board embeds an AT49BV1604 or AT49BV1614 Flash memory device programmed with default software. Evaluation Board When delivered, the Flash memory device contains: ! the Boot Software Program ! the Functional Test Software (FTS)

  • Page 14: Programmed Default Memory Mapping

    The procedure is as follows: 1. Connect the Serial A (or B ) port of the AT91EB40A Evaluation Board to a host PC Serial Port using the straight serial cable provided. 2. Start the AT91Loader.exe program available in the AT91 Library on the host com- puter.

  • Page 15: Angel Monitor

    SRAM used by Angel is from 0x00020000 to 0x0003FFFF, i.e., the highest half part of the internal SRAM. The Angel on the AT91EB40A Evaluation Board can be upgraded regardless of the ver- sion programmed on it. Note that if the debugger is started through ICE while the Angel monitor is on, the Advanced Interrupt Controller (AIC) and the USART channel are enabled.
  • Page 16 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 17: Circuit Description

    Memories The schematic (Figure 6-2 on page 6-3 in Section 6, “Appendix B – Schematics”) shows two 128K/512K x 8 SRAM devices that can be added to the AT91EB40A. Note: The AT91EB40A evaluation board does not feature any external SRAM. The user can add SRAM ranging in size from 256K bytes x 16 bits to 1M byte x 16 bits.

  • Page 18: Power And Crystal Quartz

    NWDOVF of the AT91R40008 is connected on its input /MR. The assertion of this reset signal lights the red RESET LED (D10). By pressing the CLEAR RESET push button (S2), the LED is turned off. AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 19: Layout Drawing

    The board is provided with four mounting holes, one at each corner, into which feet are attached. The board has two signal layers and two power planes. AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 20 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 21: Appendix A - Configuration Straps

    See also CB11. Open AT91 NCS0 select signal is not connected to the Flash memory. This authorizes users to connect the corresponding chip select signal to their own resources via the EBI Expansion Connector. AT91EB40A Evaluation Board User Guide Rev. 2635C–ATARM–13-May-05...
  • Page 22 The on-board reset signal is not connected to the Flash NRESET input. CB15 Flash RDY/BUSY Pin (U1B) Closed The RDY/BUSY line of the Flash memory is connected to P10/IRQ1 pin. Open The RDY/BUSY line of the Flash memory is not connected to P10/IRQ1 pin. AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 23: Ground Links (Jp6)

    The JP7A/B straps enable connection of an ammeter to measure the AT91R40008 glo- Straps (JP5A/B, bal consumption on VDDCORE. JP7A/B) Ground Links The CB10 strap allows the user to connect the electrical and mechanical grounds. (JP6) AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 24: Increasing Memory Size

    Increasing The AT91EB40A Evaluation Board is not supplied with external SRAM devices. If, how- ever, the user needs more than 256K bytes of internal memory embedded in the Memory Size AT91R40008, SRAM from 256K bytes to 1M bytes may be added.
  • Page 25 ! P1 = EBI Expansion Connector (Figure 6-6) ! P2 = I/O Expansion Connector (Figure 6-6) ! P3 = Serial A (Figure 6-3) ! P4 = Serial B (Figure 6-3) ! P5 = JTAG Interface (Figure 6-4) AT91EB40A Evaluation Board User Guide Rev. 2635C–ATARM–13-May-05...

  • Page 26: Figure 6-1. Pcb Layout

    Figure 6-1. PCB Layout AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 27: Figure 6-2. Sram Memory Devices And Two-Wire Interface Memory

    Figure 6-2. SRAM Memory Devices and Two-wire Interface Memory AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 28: Figure 6-3. Push Buttons, Leds And Serial Interface

    Figure 6-3. Push Buttons, LEDs and Serial Interface AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 29: Figure 6-4. Reset And Jtag Interface

    Figure 6-4. Reset and JTAG Interfaces AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 30 Figure 6-5. AT91R40008 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 31: Figure 6-6. I/O And Ebi Expansion Connectors

    Figure 6-6. I/O and EBI Expansion Connectors AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 32: Figure 6-7. Power Supply

    Figure 6-7. Power Supply AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...

  • Page 33: Figure 6-8. Flash Memory Devices

    Figure 6-8. Flash Memory Devices AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 34 6-10 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 35 Section 7 Appendix C – Bill of Materials Table 7-1. Bill of Materials for AT91EB40A Item Reference Part Designation Manufacturer R6 to R13, R23, R24, R104, 100 Ohm Resistor 5% R105, R107, R108 R3 to R5, R14 to R17, R22,...

  • Page 36: Figure 6-5. At91R40008

    Table 7-1. Bill of Materials for AT91EB40A (Continued) Item Reference Part Designation Manufacturer Jack Diameter 2.1 mm Jack Socket Æ 2.1mm TP1, TP2, TP3, TP4 Test Point Corner SMT Test Point 2.7 x 3.9 Sub D 9b F Sub D 9b Female socket, right...
  • Page 37 1 MB 5 Sectors Monitor Standard (8K Bytes/Sector) Mode 0x01006000 0x01005FFF 1 Sector Free Sector for (8K Bytes/Sector) Boot Upgrade 0x01004000 Flash Uploader 2 Sectors Functional Test Software (8K Bytes/Sector) Boot Program 0x01000000 AT91EB40A Evaluation Board User Guide Rev. 2635C–ATARM–13-May-05...
  • Page 38 AT91EB40A Evaluation Board User Guide 2635C–ATARM–13-May-05...
  • Page 39 Document Details Title AT91EB40A Evaluation Board User Guide Literature Number 2635 Revision History Version A Publication Date: Mar-02 Version B Publication Date: 21-Jun-02 Revisions since last issue Page: 3-2, 3-3 Change in compilation address in SRAM Downloader Version C Publication Date: 13-May-05 Revisions since last issue Section 1.3...
  • Page 40 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI- TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY...
